GIGABYTE R283-ZF1-AAL1

GIGABYTE R283-ZF1-AAL1. Processor socket: LGA 6096, Compatible processor series: AMD EPYC 9004. Supported memory types: DDR5-SDRAM, Memory channels: Dodeca-channel. Storage drive sizes supported: 2.5,M.2, Supported storage drive types: HDD & SSD, Supported storage drive interfaces: Serial ATA, Serial Attached SCSI (SAS). On-board graphics card model: Aspeed AST2600. Ethernet LAN data rates: 10,100,1000 Mbit/s, LAN controller: Intel® I350-AM2

Powering the Next Generation of Server Architecture and Energy Efficiency
The path to AMD's 5nm 'Zen 4' architecture was paved with many successful generations of EPYC innovations and chiplet designs, and AMD EPYC 9004 Series processors continue this progression. Adding a host of new features to target a wide range of workloads, the new family of EPYC processors will deliver even better CPU performance and performance per watt, and do so on a platform with 2x the throughput of PCIe 4.0 lanes that also has support for 50% more memory channels. For this new platform, GIGABYTE has products ready to get the most out of EPYC-based systems that support fast PCIe Gen5 accelerators and Gen5 NVMe drives, in addition to support for high performant DDR5 memory.

Processor

Processor socket: LGA 6096
Number of processors supported: 2
Compatible processor series: AMD EPYC 9004

Memory

Number of DIMM slots: 24
Supported memory types: DDR5-SDRAM
Memory channels: Dodeca-channel

Storage

Number of storage drives supported: 18
Feature: Hot-swap HDD bays
Number of 2.5" bays: 16
Storage drive sizes supported: 2.5,M.2
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: Serial ATA, Serial Attached SCSI (SAS)

Graphics

On-board graphics card model: Aspeed AST2600

Network

Feature: Ethernet LAN
Ethernet LAN data rates: 10,100,1000 Mbit/s
LAN controller: Intel® I350-AM2

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Ethernet LAN (RJ-45) ports: 2
Mini DisplayPorts quantity: 1

Expansion slots

PCI Express slots version: 4.0
Number of M.2 (M) slots: 2

Features

Feature: Trusted Platform Module (TPM)
Feature: Backplanes support

Design

Chassis type: Rack (2U)
Product colour: Black, Steel
LED indicators: HDD, LAN, Status

Power

Power supply: 2700 W
Number of main power supplies: 2
Feature: Redundant power supply (RPS) support
AC input voltage: 110 - 240 V
AC input frequency: 50/60 Hz
Input current: 12 - 16 A
DC output current (+12 V): 84 A
80 PLUS certification: 80 PLUS Titanium

Operational conditions

Operating temperature (T-T): 10 - 35 °C
Storage temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 8 - 80%
Storage relative humidity (H-H): 20 - 95%

Weight & dimensions

Width: 438 mm
Depth: 815 mm
Height: 87.5 mm
Weight: 30.9 kg

Packaging data

Package width: 1082 mm
Package depth: 685 mm
Package height: 314 mm
Package weight: 35.9 kg
