GIGABYTE BRIX

GIGABYTE BRIX. Product type: Mini PC barebone. Supported memory types: DDR4-SDRAM, Number of memory slots: 2, Maximum internal memory: 64 GB. Supported storage drive types: HDD SSD, Storage drive interface: PCI Express, Serial ATA III. Ethernet LAN (RJ-45) ports: 1. Bluetooth version: 5.2. Power supply: 135 W
Upgrade to the future
Minimalism meets power
The most recent generation of mainstream BRIX products adopts an all-new chassis design. Computing performance has increased, but the design does not require an increase in the size of the chassis. Its appearance has curved, soft, and twisted lines with a liveliness that makes it very unobtrusive.
By the way it was assembled and layered, and designing oblique angles around the base, a sense of simplicity is created to achieve a lightweight design. This allows users to enjoy ultimate computing performance while also having a stylish and elegant product.
With the latest 13th Gen Intel® Core™ Mobile Processors, Intel has taken its hybrid design to the next level. The new processors boast more powerful Performance-cores (P-cores), allowing for swift and seamless completion of tasks. The improved Efficient-cores (E-cores) enable even better multi-tasking, making it easier to tackle several tasks at once. These advanced processors also deliver stunning graphics and unparalleled connectivity, providing an unparalleled immersive display and lightning-fast wired and wireless connections.
Computing with ultra efficient multi-tasking
Up to 10 cores (2 P-cores, 8 E-cores) and enhanced Intel Thread Director.
Intel Iris Xᵉ Graphics
Render in the background while editing video; enjoy responsive HD gaming while streaming music; or game, stream and record at once.
Amazing End-to-End Connectivity with Wi-Fi 6
Nearly a threefold improvement in throughput speed allows for fast uploads and downloads at low latency. Intel® Wi-Fi 6 (Gig+) gives you the freedom to work and learn from anywhere—and relax with smooth, high-quality streaming.
Delivering Superior Performance Where You Need It Most
You can save time and enhance the quality of your computing experience by utilizing built-in intelligence. Enjoy features like low noise operation while collaborating and automated text, image, and audio improvements while creating. In addition, enjoy system optimization for bandwidth and video resolution while gaming on the go.

Processor

Processor manufacturer: Intel
Processor family: Intel® Core™ i3
Processor generation: Intel Core i3-13xxx
Processor model: i3-1315U
Processor cores: 6
Processor threads: 8
Processor boost frequency: 4.5 GHz
Feature: Built-in processor
Processor cache: 10 MB
Thermal Design Power (TDP): 15 W
CPU configuration (max): 1

Memory

Memory slots type: SO-DIMM
Number of memory slots: 2
Maximum internal memory: 64 GB
Supported memory clock speeds: 3200 MHz
Supported memory types: DDR4-SDRAM

Storage

Supported storage drive types: HDD SSD
Storage drive sizes supported: 2.5"
SSD form factor: M.2
Storage drive interface: PCI Express, Serial ATA III

Graphics

Feature: On-board graphics card
Graphics card family: Intel
On-board graphics card model: Intel Iris Xe Graphics

Network

Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
WLAN controller model: Intel Wi-Fi 6 AX203
Feature: Ethernet LAN
Feature: Wi-Fi
LAN controller: Intel I226-V
Feature: Bluetooth
Bluetooth version: 5.2

Ports interfaces

USB 2.0 ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 2
HDMI ports quantity: 2
HDMI version: 2.1
Feature: Combo headphone/mic port
Ethernet LAN (RJ-45) ports: 1
Feature: DC-in jack

Design

Product colour: Black
Feature: On/off switch
Feature: Cable lock slot
Cable lock slot type: Kensington
Feature: VESA mounting
Panel mounting interface: 75 x 75,100 x 100 mm
Product type: Mini PC barebone

Software

Windows operating systems supported: Windows 10, Windows 11

Power

Power supply: 135 W
AC input voltage: 100 - 240 V
AC adapter output voltage: 19.5 V
AC adapter output current: 6.92 A

Operational conditions

Operating temperature (T-T): 0 - 35 °C
Storage temperature (T-T): -20 - 60 °C

Weight dimensions

Width: 124 mm
Depth: 120 mm
Height: 49.7 mm
