bluechip BUSINESSline M1550U *AI ready*

bluechip BUSINESSline M1550U *AI ready* Intel® Core™ Ultra 5 Prozessor 225H / bis zu 4.90 GHz, Windows 11 Pro, 16 GB DDR5, 500 GB NVMe SSD, Intel® Wi-Fi 7, Bluetooth 5.4, 2,5 Gbit Ethernet, Intel® Arc™ 130T GPU, 2 × Thunderbolt™ 4. Processor family: Intel Core Ultra 5, Processor model: 225H. Internal memory: 16 GB, Internal memory type: DDR5-SDRAM, Memory clock speed: 5200 MHz. Total storage capacity: 500 GB, Storage media: SSD. On-board graphics card model: Intel Arc 130T. Wi-Fi. Operating system installed: Windows 11 Pro, Operating system architecture: 64-bit. Power supply: 120 W. Chassis type: Mini PC. Product type: Mini PC. Product colour: Black

Processor

Processor manufacturer: Intel
Processor family: Intel Core Ultra 5
Processor generation: Intel Core Ultra (Series 2)
Processor model: 225H
Processor cores: 14
Processor threads: 14
Processor boost frequency: 4.9 GHz
Performance cores: 4
Efficient cores: 8
Low Power Efficient-cores: 2
Performance-core Max Turbo Frequency: 4.9 GHz
Efficient-core Max Turbo Frequency: 4.3 GHz
Low Power Efficient-core Max Turbo Frequency: 2.5 GHz
Performance-core base frequency: 1.7 GHz
Efficient-core base frequency: 1.3 GHz
Low Power Efficient-core Base Frequency: 700 MHz
Processor cache: 18 MB
Number of processors installed: 1
Processor base power: 28 W
Maximum turbo power: 115 W

Neural processor unit (NPU)

Neural processor unit (NPU): Intel AI Boost
Sparsity support: Yes
Windows Studio effects support: Yes
AI software frameworks supported by NPU: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to: 83 TOPs
NPU performance up to: 13 TOPs
GPU performance up to: 63 TOPs

Memory

Internal memory: 16 GB
Maximum internal memory: 96 GB
Internal memory type: DDR5-SDRAM
Memory layout (slots x size): 2 x 8 GB
Memory slots: 2x SO-DIMM
Memory clock speed: 5200 MHz

Storage

Total storage capacity: 500 GB
Storage media: SSD
Optical drive type: No
Number of storage drives installed: 1
Total SSDs capacity: 500 GB
Number of SSDs installed: 1
SSD capacity: 500 GB
SSD interface: PCI Express 4.0
NVMe: Yes

Graphics

Discrete graphics card: No
On-board graphics card: Yes
Discrete graphics card model: Not available
On-board GPU manufacturer: Intel
On-board graphics card family: Intel Arc Graphics
On-board graphics card model: Intel Arc 130T

Network

Ethernet LAN: Yes
Ethernet LAN data rates: 2500 Mbit/s
LAN controller: Intel I226-V
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi standards: Wi-Fi 7 (802.11be)
WLAN controller manufacturer: Intel
WLAN controller model: Intel Wi-Fi 7 BE202
Bluetooth: Yes
Bluetooth version: 5.4

Ports interfaces

USB 2.0 ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
USB 3.2 Gen 2x2 Type-C ports quantity: 1
USB Type-C DisplayPort Alternate Mode: Yes
Intel® Thunderbolt 4: Yes
Thunderbolt 4 ports quantity: 2
HDMI ports quantity: 2
HDMI version: 2.1
Ethernet LAN (RJ-45) ports: 1

Design

Chassis type: Mini PC
VESA mounting: Yes
Product colour: Black

Performance

Audio system: High Definition Audio
Audio output channels: 7.1 channels
Trusted Platform Module (TPM): Yes
Product type: Mini PC
Trusted Platform Module (TPM) version: 2.0

Software

Operating system architecture: 64-bit
Operating system installed: Windows 11 Pro

Power

Power supply: 120 W

Certificates

Certification: CE

Weight dimensions

Width: 117 mm
Depth: 112 mm
Height: 37 mm

Display

Display included: No
