Asrock 4x4 BOX-5400U

Asrock 4x4 BOX-5400U. Chassis type: 0.6L sized PC, Product type: PC barebone. Processor socket: FP6. Number of memory slots: 2, Maximum internal memory: 64 GB. Supported storage drive types: HDD & SSD, Storage drive interface: M.2, Serial ATA III. Ethernet LAN (RJ-45) ports: 2. Power supply: 90 W

Processor

Processor manufacturer: AMD
Processor family: AMD Ryzen™ 3
Processor model: 5400U
Processor cores: 4
Processor threads: 8
Processor boost frequency: 4 GHz
Processor frequency: 2.6 GHz
Feature: Built-in processor
L3 cache: 8 MB
Thermal Design Power (TDP): 15 W

Memory

Memory slots type: SO-DIMM
Number of memory slots: 2
Maximum internal memory: 64 GB
Supported memory clock speeds: 3200 MHz
Memory channels: Dual-channel

Storage

Supported storage drive types: HDD & SSD
Storage drive sizes supported: M.2
Storage drive interface: M.2, Serial ATA III

Graphics

Feature: On-board graphics card
On-board graphics card model: AMD Radeon Graphics

Performance

Processor socket: FP6
Feature: Trusted Platform Module (TPM)
Trusted Platform Module (TPM) version: 2.0
Audio chip: Realtek ALC233

Network

Feature: Ethernet LAN

Ports & interfaces

USB 2.0 ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 2
HDMI ports quantity: 1
HDMI version: 2.0a
DisplayPorts quantity: 1
DisplayPort version: 1.2a
Ethernet LAN (RJ-45) ports: 2
Feature: DC-in jack

Design

Chassis type: 0.6L sized PC
Product colour: Black
Product type: PC barebone

Software

Windows operating systems supported: Windows 10, Windows 11

Power

Power supply type: Internal power supply unit
Power supply: 90 W

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 85 °C
Operating relative humidity (H-H): 5 - 90%
Storage relative humidity (H-H): 5 - 90%

Weight & dimensions

Width: 110 mm
Depth: 117.5 mm
Height: 47.9 mm
Weight: 1 kg
