Supermicro SuperChassis 836BA-R920B

Supermicro SuperChassis 836BA-R920B. Form factor: Rack, Type: Server, Product colour: Black. Power supply: 920 W. Supported HDD sizes: 2.5,3.5". Width: 437 mm, Depth: 648 mm, Height: 132 mm. Package weight: 32.7 kg
- 920W Redundant Power Supplies 80 PLUS, Platinum Level (94%)
- 16x 3.5" Hot-swap SAS Drive Bays w/ SES2 (dual-channel) and optional 2x 2.5" Hot-swap SAS Drive Bays on rear side of Chassis
- 1x Slim DVD-ROM Drive (optional)
- Mini-I-Pass (SFF 8087) connectivity
- 3x 8cm Hot-swap 4-pin PWM Fans
- 2x 8cm Rear-exhaust 4-pin PWM Fans
- Optional 3x slim 2.5" Internal Fixed HDD

Design

Form factor: Rack
Type: Server
Product colour: Black
Supported motherboard form factors: ATX, EATX
Number of 3.5" bays: 16
Feature: Rack mounting
Rack capacity: 3U
Feature: Reset button
LED indicators: HDD, LAN, Power, Power fail
Certification: USA - UL, FCC, CUL, CCC, EN 60950/IEC 60950, CE, TUV, 80Plus

Power supply

Feature: Power supply included
Power supply: 920 W

Ports interfaces

Audio input: No
Audio output: No
USB 2.0 ports quantity: 2

Storage

Supported HDD sizes: 2.5,3.5"

Operational conditions

Operating temperature (T-T): 10 - 35 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 8 - 90%
Storage relative humidity (H-H): 5 - 95%

Weight dimensions

Width: 437 mm
Depth: 648 mm
Height: 132 mm

Packaging data

Package weight: 32.7 kg

Logistics data

Harmonized System (HS) code: 84733080

Other features

Expansion slots: 7 x FF
Supported HDD interfaces: SAS, Serial ATA
Power requirements: 100 - 240 VAC, 50/60 Hz
Feature: Power LED
