NZXT H5 Flow

NZXT H5 Flow. Form factor: Midi Tower, Type: PC, Product colour: White. Front fans installed: 1x 120 mm, Front fans diameters supported: 120,140 mm, Rear fans installed: 1x 120 mm. Supported HDD sizes: 2.5,3.5". Width: 225 mm, Depth: 430 mm, Height: 465 mm

Design

Form factor: Midi Tower
Type: PC
Product colour: White
Supported motherboard form factors: ATX, EATX, micro ATX, Micro-ITX
Number of 3.5" bays: 1
Number of 2.5" bays: 2
Number of expansion slots: 7
Feature: Side window
Suitable for: Gaming
Feature: Tempered glass panel(s)
Feature: Anti-dust filter
Feature: Cable management
Feature: On/off button
Maximum CPU cooler height: 17.5 cm
Maximum graphics card length: 41 cm
Maximum PSU length: 20 cm

Ports & interfaces

Audio input: Yes
Audio output: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1

Cooling

Front fans installed: 1x 120 mm
Number of front fans supported (max): 3
Front fans diameters supported: 120,140 mm
Rear fans installed: 1x 120 mm
Number of rear fans supported (max): 2
Rear fans diameters supported: 120,140 mm
Number of bottom fans supported (max): 2
Bottom fans diameters supported: 120 mm
Fan speed: 1350 - 1700 RPM
Maximum airflow: 50.1 cfm
Fan 2 maximum airflow: 60.2 cfm
Maximum air pressure: 1.27 mmH2O
Fan 2 maximum air pressure: 1.05 mmH2O
Feature: Liquid cooling capability
Front radiator sizes supported: 360 mm
Top radiator sizes supported: 240 mm

Storage

Supported HDD sizes: 2.5,3.5"

Packaging content

Feature: Manual

Weight & dimensions

Width: 225 mm
Depth: 430 mm
Height: 465 mm
Weight: 7.43 kg
