HYTE Y60

HYTE Y60. Form factor: Midi Tower, Type: PC, Product colour: Black, White. Side fans diameters supported: 120,140 mm, Rear fans installed: 1x 120 mm, Rear fans diameters supported: 120 mm. Supported HDD sizes: 3.5", SSD form factor: 2.5". Width: 285 mm, Depth: 456 mm, Height: 462 mm. Package width: 372 mm, Package depth: 535 mm, Package height: 540 mm
Panoramic Views
No corner pillar. The Y60 features a 3-piece panoramic tempered glass design for the ultimate photo and display potential. See your build the way it was meant to be seen from the left or right side of your desk with a simple turn.
Exclusively Vertical GPU Mounted
Why would you want to see your graphics card any other way?
Included PCIE 4.0 Riser Cable
A protective riser cable canopy integrates beautifully into the case, allowing for half-height PCIE cards behind the throne of the vertical graphics card. The protective shroud is the first of its kind, made specifically for the Y60.
Antechamber Construction
Segment cables from thermal components and turn your PC into a work of art.
Cold Floor Cooling
Eliminate hot spots with sweeping lateral vents from fans tastefully tucked into the basement of the Y60.
Included Fans
The three pre-installed Flow FE12 fans with fluid-dynamic bearings provide whisper-quiet operation.

Design

Material: ABS, Steel, Tempered glass
Form factor: Midi Tower
Type: PC
Product colour: Black, White
Supported motherboard form factors: ATX, EATX, ITX, micro ATX
Number of 3.5" bays: 2
Number of 2.5" bays: 4
Number of expansion slots: 9
Feature: Anti-dust filter
Maximum CPU cooler height: 16 cm
Maximum graphics card length: 37.5 cm
Maximum PSU length: 23.5 cm

Ports interfaces

Audio input: Yes
Audio output: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1

Cooling

Number of side fans supported (max): 2
Side fans diameters supported: 120,140 mm
Rear fans installed: 1x 120 mm
Number of rear fans supported (max): 1
Rear fans diameters supported: 120 mm
Number of top fans supported (max): 3
Top fans diameters supported: 120 mm
Bottom fans installed: 2x 120 mm
Number of bottom fans supported (max): 2
Bottom fans diameters supported: 120,140 mm
Fan speed: 0 - 1300 RPM
Side radiator sizes supported: 120,140,240,280 mm
Rear radiator sizes supported: 120 mm
Top radiator sizes supported: 120,140,360 mm

Storage

Supported HDD sizes: 3.5"
SSD form factor: 2.5"
Number of HDDs supported: 2

Packaging content

Feature: Manual
Feature: Riser cable included

Weight dimensions

Width: 285 mm
Depth: 456 mm
Height: 462 mm
Weight: 9.6 kg

Packaging data

Package width: 372 mm
Package depth: 535 mm
Package height: 540 mm
Package weight: 11.3 kg
