Cooler Master Elite 690 Wood

Cooler Master Elite 690 Wood. Form factor: Midi Tower, Type: PC, Product colour: White. Power supply location: Bottom, Supported power supply form factors: ATX. Side fans installed: 2x 120 mm, Side fans diameters supported: 120 mm, Rear fans installed: 1x 120 mm. Supported HDD sizes: 2.5,3.5". Width: 218 mm, Depth: 434 mm, Height: 454 mm

Natural Aesthetics. Immersive View. Advanced Cooling.
Elite 690 Wood

The Elite 690 features dual tempered glass panels to showcase your build, while a wood-textured front accent and mesh intake blend warmth with airflow efficiency. With top and bottom ventilation for vertical cooling, it supports versatile fan and radiator setups—perfect for performance-driven or style-focused builds.

270° Panoramic Tempered Glass

Beveled glass panels create an immersive, seamless showcase of your build.

Natural Wood Front Panel

Crafted from real wood, the front panel adds a warm, organic touch to any space.

Optimized Tower with PSU Chamber

Vertical layout separates thermal zones for better airflow and cleaner cable routing.

Vertical Cooling Architecture

Up to 10 fans in a bottom-to-top layout maximize airflow and cooling.

Pre-installed ARGB Fans with Sync

Includes 3 daisy-chainable ARGB fans with full motherboard lighting sync support.

High-Performance Radiator Support

Top 360mm and side 240mm radiator support for powerful cooling setups.

Top & Bottom Mesh Ventilation

Mesh panels ensure enhanced airflow and system-wide thermal performance.

Next-Gen GPU Ready

Supports up to 425mm GPUs—ready for RTX 50 Series and beyond.

High-Speed I/O Panel

USB 3.2 Gen 2x2 Type-C and dual USB 3.0 ports for blazing-fast connectivity.

Design

Material: Steel, Tempered glass, Wood
Form factor: Midi Tower
Type: PC
Product colour: White
Supported motherboard form factors: ATX, ITX, micro ATX
Number of 3.5" bays: 1
Number of 2.5" bays: 1
Number of internal 3.5" bays: 1
Number of expansion slots: 7
Feature: Side window
Suitable for: Gaming
Feature: Illumination
Illumination colour: Multi
Illumination location: Case fans
Feature: Tempered glass panel(s)
Feature: Cable management
Feature: On/off button
LED indicators: Yes
Maximum CPU cooler height: 17 cm
Maximum graphics card length: 42.5 cm
Maximum PSU length: 25 cm

Power supply

Power supply location: Bottom
Supported power supply form factors: ATX

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Feature: Combo headphone/mic port
USB 3.2 Gen 2x2 Type-C ports quantity: 1

Cooling

Side fans installed: 2x 120 mm
Number of side fans supported (max): 2
Side fans diameters supported: 120 mm
Rear fans installed: 1x 120 mm
Number of rear fans supported (max): 1
Rear fans diameters supported: 120 mm
Number of top fans supported (max): 3
Top fans diameters supported: 120,140 mm
Number of bottom fans supported (max): 3
Bottom fans diameters supported: 120 mm
Feature: Liquid cooling capability
Side radiator sizes supported: 120,240 mm
Bottom radiator sizes supported: 120,240,360 mm
Top radiator sizes supported: 120,240,360 mm
Feature: Pulse-width modulation (PWM) support

Storage

Supported HDD sizes: 2.5,3.5"

Technical details

Warranty period: 2 year(s)

Weight & dimensions

Width: 218 mm
Depth: 434 mm
Height: 454 mm
Weight: 6.3 kg

Packaging data

Package width: 280 mm
Package depth: 495 mm
Package height: 515 mm
Package weight: 7.48 kg

Other features

Volume: 42.93 L
