Yealink VC200

Yealink VC200. Megapixel (approx.): 8 MP. HD type: Full HD, Maximum video resolution: 1920 x 1080 pixels, Supported video modes: 1080p, Maximum frame rate: 30 fps. Digital zoom: 4x. Wi-Fi, Bluetooth. Mounting type: Stand, Product colour: Blue, Silver

Based on Android 7.1 operating system, the Yealink VC200 is an entry-level smart video conferencing endpoint designed for small and huddle room. Its Ultra HD 4K camera and 103° super-wide angle lens deliver outstanding video quality and additional boost face-to-face collaboration. With 6 beamforming microphone arrays for direct voice pickup and Yealink Noise Proof Technology, VC200 brings excellent sound in small rooms and ensures that everyone can be heard as well as seen. For its compact six-in-one design, VC200 integrates a built-in camera, codec, microphone, Bluetooth, Wi-Fi and bracket, which provides you a turnkey solution that can be easily and consistently deployed with only two cables. The Yealink VC200 is an ideal communications choice to help ensure your teams can concentrate fully on effective collaboration.

Ultra HD 4K Camera and Super-Wide Angle Lens
The Ultra HD 4K camera supports 4x digital zoom and e-PTZ and is with super-wide 103° horizontal field of view, covering every seat at the table wholly without adjusting the camera. Featuring H.265/HEVC video codes, just with the minimum 512kbps, VC200 can realize 1080P HD video calls. Moreover, through Yealink anti-packet loss technology, VC200 can resist up to 30% video and audio packet loss which guarantees smooth video communication.

Clearer Audio with Six Beamforming Microphone Arrays
The most advanced Beamforming technology, six built-in microphone arrays, directed voice pickup, intelligent voice identification and comparison—are definitely optimized for small and huddle conference rooms. Coupled with Yealink Smart Noise Proof technology, VC200 can automatically filter out unrelated noise, making video conferencing more concentrated.
Compact Design for Fast Deployment Six-in-one design, integrating codec, camera, microphone, Bluetooth, Wi-Fi and bracket, takes up less space and minimizing cable clutter, getting ready for a video conference with only two cables (network cable and HDMI cable). Meanwhile, VC200 fits easily and seamlessly on the TV with thickness from 6mm to 50mm so that you can mount it on the top of display directly. Based on Android OS and TV-styled interactive user interface, VC200 offers all features with one-touch operation but without any learning cost.

Wireless Clutter-Free Meeting Room
Built-in Bluetooth and dual-band Wi-Fi module provide you more connection options, that neither complex installation nor messy cables are required, VC200 greatly saves your effort of deployment. In addition, VC200 not only support one-click wireless content sharing via WPP20, but also you can extend the range of voice pickup via optional wireless microphones.

Camera

Megapixel (approx.): 8 MP
Digital zoom: 4x
Horizontal field of view: 103°

Video

HD type: Full HD
Maximum video resolution: 1920 x 1080 pixels
Maximum frame rate: 30 fps
Resolution at capture speed: 1920x1080@30fps
Supported video modes: 1080p
Supported graphics resolutions: 640 x 360, 960 x 540, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Baud rate: 515 Kbit/s

Design

Product colour: Blue, Silver
Mounting type: Stand

Ports & interfaces

HDMI ports quantity: 1
USB 2.0 ports quantity: 2
Power over Ethernet (PoE) ports quantity: 1

Power

Power source type: AC, PoE
Power consumption (typical): 7 W
Power over Ethernet (PoE) voltage: 5 V

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -30 - 70 °C
Operating relative humidity (H-H): 10 - 95%

Performance

Feature: Wi-Fi
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
Feature: Bluetooth

Audio

Feature: Built-in microphone
Feature: Noise reduction

Network

Ethernet LAN data rates: 10,100 Mbit/s

Weight & dimensions

Width: 300 mm
Depth: 70 mm
Height: 86.6 mm
