Logitech Tap Scheduler video conferencing system

Logitech Tap Scheduler. Ethernet LAN, Wi-Fi. Bluetooth. Display diagonal: 25.6 cm (10.1"), Display resolution: 1280 x 800 pixels. Product colour: Graphite
Logitech Tap Scheduler
Purpose-built scheduling panel for meeting rooms
RIGHT PLACE, RIGHT TIME
Tap Scheduler makes it easy to see meeting details and reserve a room for ad hoc or future meetings. Easily deploy as a purpose-built scheduling panel for leading room scheduling solutions to help workers find and claim the right space.
GREEN MEANS GO
Quickly find an open room through colored LED lights that show availability at a distance.
CLEAN AND EASY INSTALL
Included mounts and clean cabling help ensure a tidy and professional setup.
Glass Mounting
Secure Tap Scheduler while maintaining a clean look on both sides of the glass.
Mullion Mounting
Secure Tap Scheduler to a door or window frame for greater visibility using the included mount.
Wall Mounting
Place and secure Tap Scheduler anywhere on a wall.
Cable Management
Hide cables in the wall, mullion, or in other directions, with multiple routing options.
PURPOSE-BUILT AS A SCHEDULING PANEL
Tap Scheduler was designed for easy viewing and usability, with a spacious screen and a sleek, unobtrusive profile. Count on Tap Scheduler for reliable performance with durable components that are built to last.
MAKE THE MOST OF YOUR SPACE
Easily add Tap Scheduler to a variety of meeting rooms, from phone booths to video rooms to hangout nooks, helping employees quickly find the right meeting location. Simple installations and an intuitive user experience drive fast deployment and adoption.
PICK YOUR PLATFORM
Enable a seamless meeting experience through Tap Scheduler and Logitech's suite of room solutions, which integrate with Microsoft Teams®, Zoom Rooms™, and other service providers to raise the bar on collaboration.
SIMPLE TO MANAGE WITH LOGITECH SYNC
With Logitech Sync, you can monitor and manage Tap Scheduler along with your other meeting room devices from one single platform.
UP TO THREE YEAR WARRANTY
Ensure peace of mind with an extended warranty for Tap Scheduler, adding one additional year to the standard two-year limited hardware warranty.

Performance

Bluetooth: Yes
Bluetooth version: 5.0
Product colour: Graphite

Audio

Built-in speaker(s): No

Network

Ethernet LAN: Yes
Ethernet LAN data rates: 10,100 Mbit/s
Wi-Fi: Yes
Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Networking standards: IEEE 802.3af
Security algorithms: 128-bit AES

Display

Display diagonal: 25.6 cm (10.1")
Display resolution: 1280 x 800 pixels
Contrast ratio (typical): 1000:1
Touchscreen: Yes
Display brightness: 400 cd/m²
Oleophobic coating: Yes

Logistics data

Master (outer) case gross weight: 4.66 kg
Master (outer) case length: 358 mm
Master (outer) case width: 260 mm
Master (outer) case height: 199 mm

Computer system

VESA mounting: Yes

System requirements

Minimum system requirements: Internet Connection: Wired through PoE or wireless

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 95%
Storage temperature (T-T): -40 - 70 °C

Power

Power source type: PoE

Weight dimensions

Width: 246.2 mm
Depth: 28.5 mm
Height: 165 mm
Weight: 700 g

Packaging data

Package width: 247 mm
Package depth: 346 mm
Package height: 93 mm
Package weight: 2.17 kg

Packaging content

Mounting kit: Yes
Batteries included: No
Quick start guide: Yes
Packaging content: Logitech Tap Scheduler Multi-surface mount (glass/drywall) Corner mount accessory Mullion mount Mounting hardware Documentation
