Logitech Rally Bar Huddle video conferencing system

Logitech Rally Bar Huddle Graphite. Product type: Group video conferencing system. HD type: 4K Ultra HD. Digital zoom: 4x. Ethernet LAN, Wi-Fi. Bluetooth, Product colour: Graphite

Rally Bar Huddle all-in-one video bar for huddle and small rooms.
Logitech Rally Bar Huddle is an all-in-one video conferencing bar for huddle and small meeting rooms. Designed to deliver equitable video meetings with ease, Rally Bar Huddle is quick to set up, simple to manage, and easy to integrate with Tap IP through CollabOS.
With Rally Bar Huddle, ensure everyone can be seen and heard clearly during hybrid meetings. Leveraging AI video intelligence, advanced sound pickup, noise suppression, and other ongoing software improvements, Rally Bar Huddle provides a clear and natural meeting experience for remote workers.
Plus, Rally Bar Huddle works with whatever platform you use to connect hybrid teams, ensuring a seamless experience from the home to the office, and everywhere in between. Plug and play Rally Bar Huddle with virtually any PC or Mac, or run supported video conferencing applications on the device in appliance mode without a computer.

Performance

Feature: Bluetooth
Product colour: Graphite
Camera cable length (max): 2.2 m
Product type: Group video conferencing system
Pan range: -48 - 48°
Tilt angle range: -32 - 32°
Feature: PTZ control

Video

HD type: 4K Ultra HD

Audio

Feature: Built-in speaker(s)
Line-out impedance: 4 Ω
Output voltage Total Harmonic Distortion (THD): 2%
Feature: Audio beamforming
Feature: Echo cancellation
Microphone pick-up range: 7 m
Sample rates: 0 - 48 kHz
Driver diameter: 5.5 cm
Speaker power: 8 W

Ports & interfaces

HDMI output ports quantity: 1
HDMI input ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1

Network

Feature: Ethernet LAN
Ethernet LAN data rates: 10,100,1000 Mbit/s
Feature: Wi-Fi
Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Supported network protocols: IPv4, IPv6 Proxy Support: IP based Proxy, FQDN based Proxy, Proxy using PAC file
Security algorithms: 128-bit AES

Camera

Camera type: Single camera
Feature: Zoom capability
Digital zoom: 4x
Horizontal field of view: 113°
Vertical field of view: 80°
Diagonal field of view: 120°
Feature: Privacy camera
Privacy type: Privacy shutter

Microphone

Microphone sensitivity: -36 dB
Microphone frequency: 90 - 16000 Hz
Sound pressure level (max): 83 dB
Number of microphones: 6

Computer system

Windows operating systems supported: Yes
Mac operating systems supported: MacOS

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -25 - 70 °C

Power

Power source type: AC
AC input voltage: 100-240 V
Current: 2.1 A
DC output voltage: 19 V

Weight & dimensions

Width: 549.6 mm
Depth: 76 mm
Height: 78.9 mm
Weight: 1.8 kg

Packaging data

Package width: 197 mm
Package depth: 629 mm
Package height: 118 mm
Package weight: 3.21 kg

Packaging content

Cables included: AC, DC, HDMI, USB Type-A to USB Type-C
Power cable length: 2.5 m
HDMI cable length: 2 m
Feature: AC adapter included
Packaging content: Rally Bar Huddle Multi-Mount Power supply AC power cord HDMI cable USB cable
