Honeywell Solaris XP 7990G

Honeywell Solaris XP 7990G. Type: Fixed bar code reader, Scanner type: 1D/2D, Sensor type: CMOS. Connectivity technology: Wired, Standard interfaces: RS-232. Product colour: Black, International Protection (IP) code: IP53. Power source type: AC, Input voltage: 5.2 V. Width: 152 mm, Depth: 85 mm, Height: 148 mm
With its compact, modern design and powerful imaging capabilities built on Honeywell's extreme performance (XP) platform, the Solaris 7990g fits easily into existing enclosures used in high-volume retail checkout environments such as convenience, drug, specialty, liquor and grocery stores. The Solaris XP features 20% faster scanning speed, up to 5 m/s motion tolerance, and a wider field of view than previous Solaris models. Honeywell's field proven XP technology handles poorly printed and damaged barcodes with ease. The Solaris XP is backwards compatible with previous models, making upgrades fast and simple.

Scanning

Type: Fixed bar code reader
Scanner type: 1D/2D
Sensor type: CMOS
Linear (1D) barcodes supported: Code 39 (ASCII), Code 128, EAN-13, EAN-8, UPC-A, UPC-E, Codabar, Interleaved 2 of 5
2D (matrix stacked) barcodes supported: QR Code, Data Matrix, PDF417, Aztec Code
Working distance: 100 cm
Read rate (max): 6 reads/s
Light levels (direct sunlight): 0 - 100000 lx

Ports interfaces

Connectivity technology: Wired
Standard interfaces: RS-232

Performance

International Protection (IP) code: IP53
Product colour: Black

Power

Power source type: AC
Input voltage: 5.2 V

Weight dimensions

Width: 152 mm
Depth: 85 mm
Height: 148 mm

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 0 - 95%
