Digitus DS-55317 wireless presentation system

Digitus Click Present Pro - Wireless Collaboration System. Form factor: Desktop, Product colour: Black, Grey, Housing material: Acrylonitrile butadiene styrene (ABS), Aluminium. Maximum resolution (HDMI): 3840 x 2160 pixels. Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Top Wi-Fi standard: Wi-Fi 5 (802.11ac), Frequency band: 2.4 - 5 GHz. Interface: HDMI. Power source type: DC
Wireless collaboration/presentation system - presenting from a notebook, tablet or smartphone
- Share, present collaborate from your notebook, tablet or smartphone - transmission distance of up to 50 m
- Easy installation - no software or app required
- Simultaneous presentation of up to 4 participants in split screen
- Up to 30 participants (simultaneous connection to the recipient)
- Share from your notebook via HDMI transmitter (transmitter) or via wireless screen (Windows)/screen synchronization (macOS)
- Share from your tablet/smartphone via the screen synchronization (iOS, iPadOS/Android) of your mobile device
- Touch Panel Back Control - the touch-back function of the receiver unit enables gestures/controls to be sent wirelessly back to a Windows PC using a finger on a large touchscreen
- Integrated whiteboard - the main menu of the receiver has a whiteboard function and, in combination with a touchscreen, enables quick notes to be taken during the meeting or presentation directly on the display
- Supports Windows, macOS, iOS, iPadOS, Android
- Expandable with additional HDMI transmitters (transmitters) - DS-55322
The Wireless Collaboration System from DIGITUS® combines all your devices (notebook, tablet, smartphone) and offers a hardware-based presentation solution for wireless transmission of screen content for meeting/conference rooms. Up to 30 participants can be connected to the receiver. Up to 4 participants can present/collaborate simultaneously in split-screen mode. Notebooks can be connected to the HDMI transmitter and the set can be expanded with additional transmitters (DS-55322). Alternatively, you can stream directly from the notebook (without TX) via wireless screen (Windows)/screen synchronization (macOS) to the receiver. Content from a tablet/smartphone can be conveniently shared via the sharing/cast function (iOS, iPadOS/Android) of your mobile device by connecting your mobile device to the receiver (SSID) via WLAN beforehand. The system setup has been simplified as much as possible - no additional software/apps are required. Increase the efficiency of your meetings, save time and achieve optimized results. Share - Present - Collaborate.

Design

Form factor: Desktop
Product colour: Black, Grey
Housing material: Acrylonitrile butadiene styrene (ABS), Aluminium
LED indicators: Yes

Features

Maximum resolution (HDMI): 3840 x 2160 pixels

Network

Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
Frequency band: 2.4 - 5 GHz
Dual-band: Yes
Ethernet LAN: Yes
Ethernet LAN data rates: 10,100 Mbit/s
Cabling technology: 10/100Base-T(X)
Security algorithms: 128-bit AES, WPA-PSK, WPA2, WPA2-PSK
Maximum operating distance: 50 m

Ports interfaces

Interface: HDMI
HDMI input ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
DC-in jack: Yes

Power

Power source type: DC
Power over Ethernet (PoE): No

System requirements

Windows operating systems supported: Yes
Mac compatibility: Yes
Mac operating systems supported: Yes
Other operating systems supported: Android, iOS
Mobile operating systems supported: Android, iOS

Weight dimensions

Package width: 290 mm
Package depth: 190 mm
Package weight: 1.61 kg

Packaging content

AC adapter included: Yes
Cables included: HDMI, USB

Logistics data

UK Trade Tariff code: 85176200
Country of origin: China
Harmonized System (HS) code: 85176990

Technical details

Package volume: 6061 cm³
