Cisco Room Vision

Cisco Room Vision. HD type: 4K Ultra HD, Maximum video resolution: 3840 x 2160 pixels, Supported video modes: 1080p, 2160p, Maximum frame rate: 60 fps. Optical zoom: 12x, Digital zoom: 5x. Product colour: Black
Compatibility information:
Cisco Room Bar Pro
Cisco Room Kit EQ
Cisco Room Kit EQX
Cisco Codec Pro (over HDMI only)
Cisco Board Pro 55/75 G2

Camera

Camera type: Single camera
Feature: Zoom capability
Optical zoom: 12x
Digital zoom: 5x
Combined zoom: 60x
Focal length range: 1.8 - 3.6 mm
Horizontal field of view: 80.5°
Vertical field of view: 49.2°
White balance: Auto, Manual
Focus adjustment: Auto/Manual
Closest focusing distance: 1 m
Feature: PTZ control

Video

HD type: 4K Ultra HD
Maximum video resolution: 3840 x 2160 pixels
Maximum frame rate: 60 fps
Resolution at capture speed: 1920x1080@60fps, 3840x2160@30fps
Supported video modes: 1080p, 2160p

Design

Product colour: Black
Tilt angle range: -25 - 90°
Pan range: -170 - 170°

Ports interfaces

HDMI ports quantity: 1
Power over Ethernet (PoE) ports quantity: 1
Ethernet LAN (RJ-45) ports: 1

Power

Power source type: PoE
DC input voltage: 42.5 - 57 V
Input current: 0.5 A
Power consumption (typical): 12 W

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 20 - 90%
Storage relative humidity (H-H): 10 - 90%

Network

Ethernet LAN data rates: 10,100,1000 Mbit/s

Weight dimensions

Width: 165 mm
Depth: 176 mm
Height: 196 mm
Weight: 2.3 kg
