Nicht einfach nur Datenspeicher - eine Datenstrategie
Ultrastar NVMe™ enterprise SSDs continue to be the ideal solution for cloud and server providers who need performant, high-capacity, cost-optimized, read-intensive performance for their data-intensive applications.
Unlocking the Full Potential of Enterprise SSDs
With dual-port redundancy and failover capability, end-to-end data protection and additional enterprise features, Ultrastar DC SN655 NVMe SSDs help ensure your data is secure and available when needed. With high-capacity, low-latency performance reaching up to 1.1M IOPs, storage providers are efficiently able to increase capacity for modern applications processing large unstructured datasets and are reducing time-to-insights of big data and enabling efficient machine learning.
Features
Ultrastar DC SN655 NVMe SSDs includes the next generation Western Digital NVMe 1.4b controller with PCIe Generation 4.0 interface and Western Digital BiCS5 TLC 3D NAND to enable higher capacities and performance at scale for increasingly larger application workloads. Designed and built for the standard 2.5" SSD storage infrastructure, the SN655 includes support for U.2 and U.3 backplanes and features power loss protection and 2.5M MTBF (projected) and 1.0 DW/D with a 5 year limited warranty.
Emerging Workloads
Ultrastar DC SN65x NVMe SSDs are optimized for cloud and scaleout workloads, providing high QoS consistency for the emerging workloads for big data, artificial intelligence, and machine learning that are increasing in size and complexity making them the ideal solution for scaling capacity and maximizing GB/watt.
| Atminties tipas | 3D TLC NAND |
| Atsitiktinis rašymas (4 KB) | 112000 IOPS |
| Atsitiktinis skaitymas (4 KB) | 1000000 IOPS |
| Aukštis | 15 mm |
| Bruto svoris | 0.231 kg |
| Darbinė įtampa | 12 V |
| Darbo temperatūros diapazonas (TT) | 0 - 70 °C |
| Energijos suvartojimas (tuščiąja eiga) | 8 W |
| Ilgis | 100.45 mm |
| Model | WUS5EA138ESP7E3 |
| Nekoreguojamos bitų klaidos atsiradimo dažnumas (UBER) | < 1 per 10^17 bits read |
| Neto svoris | 0.1473 kg |
| NVMe | Taip |
| Palaikoma operacinė sistema "Linux" | Taip |
| Palaikomos "Windows" operacinės sistemos | Taip |
| Plotis | 69.85 mm |
| Rašymo delsa | 10 µs |
| Rašymo laikas | 2600 MB/s |
| Sandėliavimo temperatūros norma (T-T) | -40 - 85 °C |
| Shipping Box Depth | 38.5 cm |
| Shipping Box Height | 16 cm |
| Shipping Box Weight | 2.31 kg |
| Shipping Box Width | 24 cm |
| Skaitymo delsa | 80 µs |
| Skaitymo laikas | 6800 MB/s |
| SSD disko talpa | 3840 GB |
| SSD formos koeficientas | U.3 |
| SSD series | Ultrastar DC SN655 |
| Summary | SanDisk DC SN655. SSD capacity: 3.84 TB, SSD form factor: U.3, Read speed: 6800 MB/s, Write speed: 2600 MB/s, Component for: Server/workstation |
| Svoris | 147.3 g |
| Sąsaja | PCI Express 4.0 |
| Taikoma | Serveriui / darbo stočiai |
| Unit Box Height | 0.015 |
| Unit Box Length | 0.1 |
| Unit Box Width | 0.07 |
| Unit Brutto Volume | 0.001478 cubm |
| Vendor Homepage | https://www.westerndigital.com/de-de/products/internal-drives/data-center-drives/ultrastar-dc-sn655-nvme-ssd?sku=0TS2463#0TS2463 |
| Vidutinis laikas tarp trikčių (MTBF) | 2500000 h |
| Vieneto aukštis | 1.5 cm |
| Vieneto gylis | 10 cm |
| Vieneto plotis | 7 cm |
| Vienetų skaičius vienoje siuntimo dėžėje | 10 |
| "NVMe" versija | 1.4b |
