MIMOSA X-Series 30 dBi Gain Horn Antenna for C6x, C6x Lite Edition and B6x radios (2-pack)

Precision-engineered twist-on antennas designed to optimize performance, reduce interference, and adapt to any deployment scenario.

The Mimosa N5-X Antenna family delivers flexible, highperformance antenna options designed to meet the evolving needs of modern fixed wireless networks—from broad coverage applications to long-range, high-capacity precision links. Purpose-built for seamless integration with the Mimosa C6x, C6x Lite Edition, and B6x platforms, N5-X antennas help operators optimize signal quality, improve link stability, and reduce interference using Mimosa's simple twist-on architecture. With multiple gain and beamwidth options available, operators can tailor deployments for point-to-multipoint access, last-mile connectivity, or carrier-grade backhaul without adding unnecessary omplexity to installation or network expansion.

Designed for real-world deployment flexibility, the N5-X portfolio enables operators to deploy smarter while adapting to changing coverage and capacity requirements over time. For longer-distance or higher-throughput backhaul applications, Mimosa recommends pairing the B6x with the high-gain N5-X30 antenna to maximize

performance and link efficiency. Mimosa also offers adapter options for select deployment scenarios, including support for certain third-party dish integrations where additional mounting or interface compatibility may be required. Whether extending broadband into rural communities, supporting dense suburban growth, or building scalable multi-link wireless infrastructure, the N5-X family provides the right gain, coverage, and deployment flexibility to help operators build reliable networks with confidence.

Product: N5-X20kp (2-pack)

Gain: 30 dBi

Polarization: Dual-slant 45º

Beamwidth, Symmetric (3 dB): 5.5º-6º

Front-to-Back Ratio (min): 35 dB

Front-to-Side Ratio (min): 30-35 dB

Weight: 6.5 kg

Dimensions:

Diameter: 600 mm (23.62")

Depth: 330.2 mm (13")

Mount: Mimosa N5-X twist-on

Wind Survivability: 200 km/h (125 mph)

Wind Loading: 44-55 kg @ 160 km/h (100 mph)
