Access Point - TP-Link Omada EAP603-Outdoor White
Product reference:
14-1210002605731
Outdoor wireless access point with Wi-Fi 6 and dual-band connectivity, providing speeds of up to 1,800 Mbps and one Gigabit Ethernet port. The white housing mounts to a pole or wall, supports passive PoE, has IP65/IP66 protection and operates in temperatures from −30 to 70 °C.
Access Point - TP-Link Omada EAP603-Outdoor White
Product reference:
14-1210002605731
Outdoor wireless access point with Wi-Fi 6 and dual-band connectivity, providing speeds of up to 1,800 Mbps and one Gigabit Ethernet port. The white housing mounts to a pole or wall, supports passive PoE, has IP65/IP66 protection and operates in temperatures from −30 to 70 °C.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
15 - 16
business days
TP-Link Omada EAP603-Outdoor White
Outdoor Wi-Fi 6 access point with dual-band speeds of up to 1800 Mbps and one Gigabit Ethernet port. The white, pole- or wall-mountable housing supports passive PoE, has IP65/IP66 protection, and operates in temperatures from −30 to 70 °C.
- Outdoor Wi-Fi 6 access point providing dual-band speeds of up to 1,800 Mbps.
- Provides reliable wireless connectivity up to 300m away and supports seamless roaming.
- Weatherproof housing with IP65/IP66 protection for pole or wall mounting.
- Cloud-managed, supports PoE, guest access, multiple SSIDs, and advanced security features.
Product information | |
|---|---|
| Product type | Outdoor Wi-Fi 6 access point |
| Manufacturer | TP-Link Omada |
| Model | EAP603-Outdoor |
| Color | White |
Wireless specifications | |
| Wireless communication standard | IEEE 802.11ax (Wi-Fi 6), 802.11a/b/g/n |
| Wireless frequency bands | 2.4GHz and 5GHz |
| Maximum data transfer rate | 1,800 Mbps |
| Maximum data transfer rate at 2.4 GHz | 573 Mbps |
| Maximum data transfer rate at 5 GHz | 1,201 Mbps |
| Bluetooth | Yes |
| Wireless range | Up to 300 m outdoors |
Network and security | |
| Ethernet port | 1 × Gigabit Ethernet RJ-45 |
| Ethernet speed supported | 10/100/1000 Mbps |
| Supported SSIDs | Up to 16 |
| Authentication and encryption | WPA2 and WPA3 Personal and Enterprise, RADIUS, EAP, SSH and SNMP |
| Network controllers | Guest access, MAC filtering, IP filtering, ACL and multiple SSIDs |
| Roaming support | IEEE 802.11k, 802.11r and 802.11v |
Installation and protection | |
| Installation options | Mounting to a pole or wall |
| Environmental protection class | IP65/IP66 |
| Antenna configuration | 4 omnidirectional antennas, up to 5 dBi gain |
| Operating temperature | From −30 to 70 °C |
| Operating humidity | 10-90% relative humidity |
Power and control | |
| Power supply method | Passive Power over Ethernet (PoE) |
| Input voltage | 42.5-57V DC |
| Maximum power consumption | 4.8W |
| Management | Cloud and web-based management with backup function |
Dimensions and equipment | |
| Dimensions | 230 × 69.7 × 207.5 mm (width × height × depth) |
| Included accessories | PoE adapter, installation kit and quick start guide |
Safety warning | |
| Warning | Use only for wireless network access and install according to manufacturer's instructions. Use compatible PoE equipment and ensure that all outdoor connections are properly protected from moisture. Disconnect the device from the power source before installation or maintenance. |
| Height | 100mm |
| Length | 300mm |
| Weight | 700g |
| Width | 250mm |
