Nikon WT-7A Wireless Transmitter (Z6,Z7,D500,D780,D850, etc.)

Nikon WT-7A Wireless Transmitter(Z6,Z7,D500,D780,D850,D810,D810A,D750,D7200)

This compact, highly efficient transmitter provides a connection between the camera and a wireless network up to 200 m away, at speeds of up to 866.7 Mbps. It supports wireless LAN IEEE 802.11ac.

It features access point, HTTP and FTP connection modes, and can be used with multiple cameras simultaneously. Remote control of camera settings and live view output can be used in HTTP mode or on a computer running Nikon Camera Control Pro 2 software. HTTP mode allows you to use any web browser, including that on a smart device, and control remotely via a wireless or cabled Internet connection.

The WT-7A Wireless Transmitter is powered by a single EN-EL15¹ battery.

¹not included (in the package)EN-EL15 battery not included) Compatibility*:

Nikon D500, D780, D850, Z6, Z7 (all camera software supported)

Nikon D810 (requires C software version 1.12 or later)

Nikon D810A (requires C software version 1.02 or later)

Nikon D750 (requires C software version 1.11 or later)

Nikon D7200 (requires C software version 1.02 or later)

More information about compatibility and support:https://www.nikonimgsupport.com/eu/BV_article?articleNo=000006299configured=1lang=en_GB#WT-7

*Latest WT-7A wireless transmitter software update required for full support.

Technical data

Ethernet connection and standards

1 x RJ-45 (802.3ab, 802.3u, 802.3 Ethernet)

10/100/1000 Mbps (auto-sensing)

Wireless standards

802.11ac, 802.11a/b/g/n

Operating frequency (MHz)

WT-7A: 5180-5320 MHz(36/40/44/48/52/56/60/64 channels) 5745-5825 MHz(149/153/157/161/165 channels) 2412-2462 MHz (1-11 channels)

Approximate range (line of sight)1

Approximately 200 m (656.1 ft)

Data transfer speed2

802.11a/g: 6,9,12,18,24,36,48,54 Mbps

802.11b: 1,2,5.5,11Mbps

802.11n: 300Mbps (maximum)

802.11ac: 866.7 Mbps (maximum)

Security authentication

Open system, shared key, WPA-PSK, WPA2-PSK

Encryption

128/64-bit WEP, TKIP, AES

Wireless setup

WPS 2.0 support

Access protocols

Infrastructure network, special

Energy source

Rechargeable EN-EL15 Li-ion battery 1x - purchase separately (not included)

EP-5B charging cable and EH-5b AC adapter - optional purchase (not included)

Working environment

Temperature: 0-40°C / 32-131°F; Humidity: less than 85% (non-condensing)

Weight

Approximately 175g / 6.2oz (body only)

Dimensions (W × H × D)

Approximately 135 × 37 × 60 mm

1. With a large antenna on the wireless LAN access point. The range is determined by the signal strength and the presence of foreign objects.

2. Maximum theoretical data rate per IEEE standard. Actual speed may vary.
