TP-Link Omada ES224G network switch Managed L2 Gigabit Ethernet (10 / 100 / 1000) Black
Product reference:
6-ES224G
TP-Link Omada ES224G network switch Managed L2 Gigabit Ethernet (10/100/1000) Black
TP-Link Omada ES224G network switch Managed L2 Gigabit Ethernet (10 / 100 / 1000) Black
Product reference:
6-ES224G
TP-Link Omada ES224G network switch Managed L2 Gigabit Ethernet (10/100/1000) Black
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
60 month
Delivery from Europe in
4 - 8
business days
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Auto MDI/MDI-X | Yes |
| Auto-negotiation | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Broadcast storm control | Yes |
| Cables included | AC |
| Cloud-managed | Yes |
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
| Depth | 140 mm |
| DHCP features | DHCP client |
| Fanless | Yes |
| Fast leave | Yes |
| Firmware upgradeable | Yes |
| Flow control support | Yes |
| Forwarding rate | 35.7 Mpps |
| Gigabit Ethernet (copper) ports quantity | 24 |
| Height | 44 mm |
| IGMP snooping | Yes |
| Jumbo frames | 15000 |
| Jumbo frames support | Yes |
| Link aggregation | Yes |
| MAC address table | 8000 entries |
| Multicast support | Yes |
| Number of VLANs | 32 |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -5 - 50 °C |
| Packet buffer memory | 4 MB |
| Port mirroring | Yes |
| Power source | AC |
| Power supply included | Yes |
| Product colour | Black |
| Quality of Service (QoS) support | Yes |
| Queue scheduling algorithms | Weighted Round Robin (WRR) |
| Rack mount kit | No |
| Rack mounting | Yes |
| Storage relative humidity (H-H) | 5 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
| Store-and-forward | Yes |
| Surge protection | Yes |
| Surge protection voltage | 6 kV |
| Switch layer | L2 |
| Switch type | Managed |
| Switching capacity | 48 Gbit/s |
| Unified static configuration | Yes |
| User guide | Yes |
| Virtual LAN features | MTU VLAN, Port-based VLAN |
| VLAN support | Yes |
| Web-based management | Yes |
| Width | 294 mm |
