VALUE 21.99.1199 network media converter

VALUE 21.99.1199. Maximum data transfer rate: 1000 Mbit/s, Converter input interface: 10Base-T, 100Base-TX, 1000Base-TX, 1000Base-X, Converter output interface: 100Base-FX. Fiber mode structure: Multi-mode, Fiber cable diameters supported (core/cladding): 50/125,62.5/125 µm. Product colour: Black. Fiber optic connector: LC, Connectivity technology: Wired. Output voltage: 5 V, Output current: 1 A, Power consumption (typical): 3 W

Converts a 10/100/1000 Mbit/s TP port to Gigabit Ethernet fiber - single mode or multimode, depending on the SFP used
Supports full wire speed conversion for 10/100/1000 Mbit/s speed and media types
Protocols: IEEE802.3 Ethernet / IEEE802.3i 10Base-Tx / IEEE802.3u 100Base-Tx/Fx / IEEE802.3z 1000Base-X / IEEE802.3ab 1000Base-Tx / IEEE802.3x Flow control

TP port:
- IEEE 802.3 10Base-T, IEEE 802.3u/3i/3z/3ab/3x
- Shielded RJ-45 jacks with auto MDI/MDI-X detection
- Auto-negotiation for speed and duplex auto detection
- Speed for 10/100/1000 Mbit/s, Full/half-duplex support

FX port:
- IEEE 802.3u 100Base-FX compliant
- Forced 100Mbit/s, Full-duplex
- For multimode fibre cable: 62.5/125µm and 50/125µm

Low power consumption: 3W
Power over included power supply (5VDC, 1A)
Remark: The converters do not offer a repeater function!

Contents: Converter, power supply, manual

Network

Maximum data transfer rate: 1000 Mbit/s
Converter input interface: 10Base-T, 100Base-TX, 1000Base-TX, 1000Base-X
Converter output interface: 100Base-FX
Networking standards: IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Ethernet interface type: Gigabit Ethernet
Ethernet LAN data rates: 10,100 Mbit/s
Feature: Auto MDI/MDI-X
Feature: Auto-negotiation
Duplex system: Full, Half

Performance

Fiber mode structure: Multi-mode
Fiber cable diameters supported (core/cladding): 50/125,62.5/125 µm

Features

Product colour: Black

Ports & interfaces

Connectivity technology: Wired
Ethernet LAN (RJ-45) ports: 1
Fiber ports quantity: 1
Fiber optic connector: LC

Power

Output voltage: 5 V
Output current: 1 A
Power consumption (typical): 3 W

Weight & dimensions

Width: 71 mm
Depth: 94 mm
Height: 26 mm
Weight: 160 g

Operational conditions

Operating temperature (T-T): 0 - 65 °C
