VALUE 21.99.1195 network switch

VALUE 21.99.1195. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. MAC address table: 8000 entries, Switching capacity: 18 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3x. Power connector: AC-in jack. Power over Ethernet (PoE)

Gigabit Ethernet PoE+ switch with 8+2 ports for small or medium-sized network environments.

In addition to the Gigabit Ethernet switch function, the device takes care of a stable PoE supply of your network environment from network cameras, access points, IP phones and much more.

PoE/PoE+ resource management: the switch supports PoE/PoE+ connections with up to 30W per port. Total switch consumption is limited to 120 watts to prevent excessive heat dissipation. With Power over Ethernet, the ports are prioritized numerically (1-2-3-...) and switched off from back to front at full load.

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Power connector: AC-in jack

Network

Networking standards: IEEE 802.3af, IEEE 802.3x
Copper ethernet cabling technology: 1000BASE-T
Feature: Auto MDI/MDI-X
Feature: VLAN support
Number of VLANs: 1

Data transmission

Switching capacity: 18 Gbit/s
MAC address table: 8000 entries
Feature: Store-and-forward

Design

Product colour: Black
Housing material: Metal
LED indicators: Link, Power

Power

Feature: Power supply included
AC input voltage: 220 - 240 V

Power over Ethernet (PoE)

Feature: Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 120 W

Weight & dimensions

Width: 210 mm
Depth: 150 mm
Height: 32 mm
Weight: 1.2 kg

Packaging content

Cables included: AC
Feature: Manual
