Ubiquiti Wave AP Gen2

Ubiquiti Wave AP Gen2. Maximum transfer distance: 6000 m. Antenna connector type: RP-SMA, Antenna gain level (max): 20 dBi. Top Wi-Fi standard: Wi-Fi 6 (802.11ax), Frequency band: 57 - 71 GHz, Modulation: 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, QPSK. Ethernet LAN interface type: 2.5 Gigabit Ethernet, Ethernet LAN data rates: 10,1000,2500 Mbit/s, Number of users: 31 user(s). Connectivity technology: Wired Wireless
60 GHz + 5 GHz multipoint base station featuring 90-degree sectoral coverage, 31-client capacity, 2.7 Gbps symmetrical speed, and antenna connectors for 5 GHz range extension.

Data transmission

Maximum transfer distance: 6000 m

Antenna

Antenna connector type: RP-SMA
Antenna gain level (max): 20 dBi

Wireless LAN features

Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Frequency band: 57 - 71 GHz
Modulation: 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, QPSK

Network

Ethernet LAN: Yes
Ethernet LAN interface type: 2.5 Gigabit Ethernet
Ethernet LAN data rates: 10,1000,2500 Mbit/s
Number of users: 31 user(s)

Ports interfaces

Connectivity technology: Wired Wireless
Ethernet LAN (RJ-45) ports: 1
Power over Ethernet plus (PoE+) ports quantity: 1

Security

Security algorithms: AES, SNMP, WPA2-PSK

Features

Product type: Network bridge
Material: Aluminium, Polycarbonate (PC)
Mounting type: Pole
Product colour: White
LED indicators: GPS, LAN, Power
Reset button: Yes
International Protection (IP) code: IPX6
Network Time Protocol (NTP) client: Yes
Processor frequency: 1.4 MHz
Internal memory: 512 MB

Power

Power consumption (max): 24 W
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) voltage: 48 V

Operational conditions

Operating temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 5 - 95%

Certificates

Compliance certificates: CE, Federal Communications Commission (FCC), Industry Canada (IC)

Weight dimensions

Width: 158.3 mm
Depth: 100.2 mm
Height: 286.8 mm
Weight: 1.5 kg

Packaging content

Power supply included: Yes

Packaging data

Quantity per pack: 1 pc(s)
