Ubiquiti UniFi USW-ENTERPRISE-48-POE network switch

Ubiquiti UniFi USW-ENTERPRISE-48-POE. Switch type: Managed, Switch layer: L3. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 48. Switching capacity: 360 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at. DC input voltage: 52 V

The Switch Enterprise 48 PoE (USW Enterprise 48 PoE) is a fully managed switch with (48) 2.5GbE, 802.3at PoE+ RJ45 ports, (4) 10G SFP+ ports, and a 720W total PoE supply. Along with its Layer 3 functionality, this switch offers an extensive suite of Layer 2 switching protocols, including port-specific operation modes (switching, mirroring, or aggregate).The USW Enterprise 48 PoE also features a 1.3" LCM color touchscreen that concisely displays key system and connection insights.

Additionally, the USW Enterprise 48 PoE offers enhanced power supply failure protection when connected to the SmartPower Redundant Power System (USP RPS sold separately). This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.

Management features

Switch type: Managed
Switch layer: L3
Feature: Web-based management

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 48
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
SFP+ module slots quantity: 4

Network

Networking standards: IEEE 802.3af, IEEE 802.3at
Feature: 10G support

Data transmission

Switching capacity: 360 Gbit/s
Throughput: 160 Gbit/s
Forwarding rate: 238.095 Mpps

Design

Product colour: White
Housing material: Steel
Feature: Reset button

Power

Power source: AC/DC
Feature: Redundant power supply (RPS) support
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
DC input voltage: 52 V
Input current: 10 A

Operational conditions

Operating temperature (T-T): -5 - 40 °C
Operating relative humidity (H-H): 10 - 90%

Weight & dimensions

Width: 442 mm
Depth: 400 mm
Height: 44 mm
Weight: 6.2 kg

Certificates

Compliance certificates: CE

Logistics data

Harmonized System (HS) code: 85176990
