Ubiquiti UniFi USW-ENTERPRISE-24-POE-EU network switch

Ubiquiti UniFi USW-ENTERPRISE-24-POE-EU. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 24, Console port: RJ-45. Switching capacity: 124 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at. DC input voltage: 52 V. Power over Ethernet (PoE)

The Switch Enterprise 24 PoE (USW Enterprise 24 PoE) is a fully managed, Layer 3 switch with (12) 2.5GbE, 802.3at PoE+ RJ45 ports, (12) GbE, 802.3at PoE+ RJ45 ports, (2) 10G SFP+ ports, and a 400W total PoE supply. The USW Enterprise 24 PoE also features a 1.3" LCM color touchscreen that concisely displays key system and connection insights.
Additionally, the USW Enterprise 24 PoE offers enhanced power supply failure protection when connected to the SmartPower Redundant Power System (USP RPS sold separately). This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.

Management features

Switch type: Managed

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
SFP+ module slots quantity: 2
Console port: RJ-45

Network

Networking standards: IEEE 802.3af, IEEE 802.3at
Feature: 10G support
Ethernet LAN data rates: 10,100,1000,5000 Mbit/s

Data transmission

Switching capacity: 124 Gbit/s
Throughput: 62 Gbit/s
Forwarding rate: 92.25 Mpps

Design

Product colour: White
Housing material: Steel

Power

Feature: Power supply included
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
DC input voltage: 52 V
Input current: 8.5 A
Power consumption (typical): 34.2 W
Power consumption (max): 550 W

Power over Ethernet (PoE)

Feature: Power over Ethernet (PoE)
Power over Ethernet (PoE) type supported: Active PoE
Power over Ethernet (PoE) power per port: 34.2 W

Operational conditions

Operating temperature (T-T): -5 - 40 °C
Operating relative humidity (H-H): 10 - 95%

Weight & dimensions

Width: 442.2 mm
Depth: 325 mm
Height: 43.7 mm
Weight: 5.2 kg

Certificates

Certification: CE, FCC, IC

Logistics data

Harmonized System (HS) code: 85176990
