Ubiquiti EdgeSwitch 24 250W

Ubiquiti EdgeSwitch 24 250W. Switch type: Managed, Switch layer: L2/L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24, Console port: RJ-45. Full duplex. MAC address table: 16384 entries, Switching capacity: 52 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE.... Power over Ethernet (PoE). Rack mounting, Form factor: 1U

The Ubiquiti Rackmount EdgeSwitch 24 250W ES-24-250W delivers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.
The EdgeSwitch is a fully managed, PoE+ Gigabit switch, delivering robust performance and intelligent switching for growing networks. The EdgeSwitch offers an extensive suite of advanced Layer-2 switching features and protocols, and also provides Layer-3 routing capability.

Management features

Switch type: Managed
Switch layer: L2/L3
Feature: Quality of Service (QoS) support
Feature: Web-based management
Feature: Configuring Location Settings (CLI)
Feature: System event log

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 24
SFP module slots quantity: 2
Console port: RJ-45

Network

Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Feature: Port mirroring
Feature: Full duplex
Feature: Half duplex
Feature: Flow control support
Feature: Link aggregation
Feature: Broadcast storm control
Feature: Spanning tree protocol
Ethernet LAN data rates: 10,100,1000 Mbit/s
Feature: Auto-sensing
Feature: VLAN support
Virtual LAN features: Private VLAN, Tagged VLAN, Voice VLAN
Number of VLANs: 4093

Data transmission

Switching capacity: 52 Gbit/s
Forwarding rate: 38.69 Mpps
MAC address table: 16384 entries
Number of queues: 8
Feature: Static route
Feature: Jumbo frames support

Security

DHCP features: DHCP server, DHCP snooping
Feature: Access Control List (ACL)
Feature: IGMP snooping
Security algorithms: SSH-1.5, SSH-2, SSL/TLS
Feature: MAC address filtering
Authentication: Guest VLAN, Port-based authentication
Authentication type: IEEE 802.1x, RADIUS

Multicast features

Feature: Multicast support

Protocols

Management protocols: SNMP v1/v2/v3, Telnet

Design

Feature: Rack mounting
Form factor: 1U
Product colour: Black
LED indicators: Activity, Link, PoE, Speed

Power

Feature: Power supply included
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power consumption (max): 250 W

Power over Ethernet (PoE)

Feature: Power over Ethernet (PoE)
Power over Ethernet (PoE) type supported: Active PoE, Passive PoE
Power over Ethernet (PoE) power per port: 34.2 W

Operational conditions

Operating temperature (T-T): -5 - 40 °C
Operating relative humidity (H-H): 5 - 95%

Weight & dimensions

Width: 485 mm
Depth: 285.4 mm
Height: 43.7 mm
Weight: 4.7 kg

Certificates

Certification: ETSI300-019-1.4CE, FCC, IC

Logistics data

Harmonized System (HS) code: 85176990
