Trendnet TPE-117GI PoE adapter

Trendnet TPE-117GI. Ethernet interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.3bt, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u. Product colour: Black. AC adapter input voltage: 100 - 240 V, AC adapter frequency: 50/60 Hz, Input current: 2 A. Certification: FCC, CE. Weight: 185 g, Dimensions (WxDxH): 120 x 75 x 22 mm
TRENDnet's Gigabit Ultra PoE+ Injector, model TPE-117GI, combines electrical power with a Gigabit network connection to produce a Gigabit Ultra Power over Ethernet Plus signal. Auto-sensing technology conveniently delivers the correct wattage needed to power your Ultra PoE devices and PoE+ devices. Use an existing open port from a non-PoE switch to save installation and equipment costs when installing TRENDnet PoE access points and IP cameras in remote locations.

Network

Ethernet interface type: Gigabit Ethernet
Ethernet LAN data rates: 10,100,1000 Mbit/s
Power over Ethernet (PoE): Yes
Networking standards: IEEE 802.3bt, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Duplex system: Full

Features

Product colour: Black
LED indicators: Yes

Ports interfaces

DC-in jack: Yes

Power

AC adapter input voltage: 100 - 240 V
AC adapter frequency: 50/60 Hz
Input current: 2 A
Output current: 1.38 A
Power consumption (max): 5 W
Power over Ethernet (PoE) power per port: 60 W
Total Power over Ethernet (PoE) budget: 60 W

Certificates

Certification: FCC, CE

Operational conditions

Operating temperature (T-T): 0 - 60 °C

Weight dimensions

Weight: 185 g
Dimensions (WxDxH): 120 x 75 x 22 mm

Packaging content

Number of products included: 1 pc(s)

Logistics data

Harmonized System (HS) code: 85044095
