Trendnet TL2-F7120 network switch

Trendnet TL2-F7120. Switch type: Managed. Console port: RJ-45. Full duplex. MAC address table: 32000 entries, Switching capacity: 240 Gbit/s. Networking standards: IEEE 802.1AX, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE.... Rack mounting, Form factor: 1U

TRENDnet's 12-Port 10G Layer 2 Managed SFP+ Switch, model TL2-F7120, offers advanced traffic management controls to meet the evolving demands of SMB networks. This rack-mountable IPv6-ready managed switch comes with an intuitive web-based interface. Advanced management features on this ultra-fast 10G SFP+ switch include LACP to increase bandwidth between switches TL2-F7120 by grouping ports together, VLANs for segmenting and isolating virtual LAN groups, QoS for traffic prioritization, port bandwidth controls, and SNMP monitoring, making this a powerful solution for any SMB network. Improve voice performance by isolating and
prioritizing VoIP traffic from normal data traffic with an easy-to-use voice VLAN feature.
Free up router resources by offloading routing processes to this 10G managed SFP+ switch by using the L2+ IPv4/IPv6 static routing feature to efficiently route traffic at the switch level. Take advantage of the available multicast and IGMP/MLD snooping features to optimize IP surveillance system performance, and minimize network traffic. TRENDnet's 10G SFP+ switch features 12 x 10GSFP+ slots for high-speed network uplinks or downlink NAS/access server connections, providing a cost-effective solution in adding 10G link capability to an SMB network.

Management features

Switch type: Managed
Feature: Configuring Location Settings (CLI)

Ports & interfaces

Basic switching RJ-45 Ethernet ports type: No
SFP+ module slots quantity: 12
Console port: RJ-45

Network

Feature: 10G support
Feature: Full duplex
Feature: Link aggregation
Feature: Broadcast storm control
Feature: Spanning tree protocol
Feature: VLAN support
Virtual LAN features: Tagged VLAN, Voice VLAN
Number of VLANs: 4094

Data transmission

Switching capacity: 240 Gbit/s
Forwarding rate: 178.6 Mpps
MAC address table: 32000 entries
Feature: Store-and-forward
Feature: Jumbo frames support
Jumbo frames: 10000
Packet buffer memory: 2 MB

Security

DHCP features: DHCP snooping
Feature: IGMP snooping

Multicast features

Feature: Multicast support

Protocols

Management protocols: SNMP v1, v2c, v3

Design

Feature: Rack mounting
Form factor: 1U
Product colour: Black
Number of fans: 1 fan(s)

Performance

Noise level: 38.6 dB

Power

Power source: AC
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Input current: 1.5 A
Power consumption (max): 20 W

Operational conditions

Operating temperature (T-T): 0 - 50 °C

Weight & dimensions

Width: 210 mm
Depth: 230 mm
Height: 44 mm
Weight: 1.6 kg

Certificates

Certification: CEFCCUL
