Trendnet TEG-10GECTX network card

Trendnet TEG-10GECTX. Internal. Connectivity technology: Wired, Host interface: PCI Express, Interface: Ethernet. Maximum data transfer rate: 10000 Mbit/s. Product colour: Green, Grey

TRENDnet's 10 Gigabit PCIe Network Adapter, model TEG-10GECTX, converts a free PCI Express slot into a 10 Gigabit Ethernet port.

10 G Port

Supports five selectable speeds: 10 Gbps, 5 Gbps, 2.5 Gbps, 1 Gbps, and 100 Mbps

PCI Express

Converts a PCIe 2.0 x4 slot into a 10 G Ethernet Port

NBASE-T™ Ethernet Technology

NBASE-T draft specification supports 2.5 and 5 Gbps speeds over standard Cat 5e cables at distances up to 100 m

Jumbo Frame

Sends larger packets, or jumbo frames (up to 16 KB), for increased performance

VLAN Support

IEEE 802.1Q tagged-based VLAN support

Brackets

Supports most installations with included standard and low-profile brackets

Operating Systems

Compatible with Windows®, Windows Server®, and Linux® operating systems.

LED Indicators

LED indicators convey port status, link speed and activity.

Ports & interfaces

Connectivity technology: Wired
Host interface: PCI Express
Interface: Ethernet
Ethernet LAN (RJ-45) ports: 1

Network

Maximum data transfer rate: 10000 Mbit/s
Networking standards: IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3an, IEEE 802.3u
Feature: Ethernet LAN
Ethernet interface type: 10 Gigabit Ethernet
Ethernet LAN data rates: 10,100,1000,10000 Mbit/s
Copper ethernet cabling technology: 10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T
Feature: Jumbo frames support
Jumbo frames: 16000
Feature: VLAN tagging

Design

Product colour: Green, Grey
Feature: Internal
LED indicators: Yes
Certification: FCC, CE

System requirements

Windows operating systems supported: Yes
Linux operating systems supported: Yes

Operational conditions

Operating temperature (T-T): 0 - 50 °C

Weight & dimensions

Width: 84 mm
Depth: 18 mm
Height: 63 mm
Weight: 62 g

Packaging data

Feature: Low-profile bracket

Packaging content

Feature: Mounting brackets included
Feature: Manual

Logistics data

Harmonized System (HS) code: 85176990

Other features

Feature: Quick start guide
Feature: Receive Side Scaling (RSS)
