TP-Link VIGI InSight S345ZI

TP-Link VIGI InSight S345ZI. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Wall, Product colour: White, Form factor: Bullet. Angle of rotation: 360°, Lens viewing angle, horizontal: 29.6-102, Lens viewing angle, vertical: 16.8-53.8. Sensor type: CMOS, Optical sensor size: 25.4 / 2.9 mm (1 / 2.9"). Optical zoom: 5x, Focal length range: 2.7 - 13.5 mm, Focus: Motorized

See Every Detail Up Close

4MP Outdoor IR Motorized Varifocal Bullet Network Camera

Motorized Varifocal

By adjusting the field of view (FOV), this feature assists you in concentrating on areas of interest, minimizing invalid detection zones, and enhancing target clarity.

Greater Clarity While Zooming

Human & Vehicle Classification

Distinguish humans and vehicles from other objects and receive more accurate event notifications.

Smart Video Enhancement Technology

- True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.
- Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.
- 3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.
- White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.

Efficient H.265+ Compression Technology

H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.**

Performance

Type: IP security camera
Placement supported: Outdoor
Connectivity technology: Wired
Feature: Wide Dynamic Range (WDR)
Feature: Day/night mode
Feature: Infrared (IR) cut-off filter
Feature: Remote viewing
Dynamic range: 120 dB

Design

Form factor: Bullet
Mounting type: Wall
Product colour: White
Housing material: Metal
Protection features: Waterproof
International Protection (IP) code: IP67
Feature: Weatherproof

Camera

Minimum illumination: 0 lx
Angle of rotation: 360°
Lens viewing angle, horizontal: 29.6-102
Lens viewing angle, vertical: 16.8-53.8
Lens viewing angle, diagonal: 34.1-122.8
Tilt angle range: 0 - 90°
Pan range: 0 - 360°
Camera shutter speed: 1/3 to 1/10000

Image sensor

Optical sensor size: 25.4 / 2.9 mm (1 / 2.9")
Feature: Progressive scan
Sensor type: CMOS

Lens system

Feature: Zoom capability
Optical zoom: 5x
Number of lenses: 1
Focal length range: 2.7 - 13.5 mm
Focus: Motorized
Maximum aperture number: 1.6
Detect distance (wide): 66 m
Detect distance (tele): 207 m
Observe distance (wide): 28 m
Observe distance (tele): 86 m
Recognize distance (wide): 13 m
Recognize distance (tele): 41 m
Identify distance (wide): 7 m
Identify distance (tele): 21 m

Night vision

Feature: Night vision
Night vision distance: 10 m
LED type: IR
Number of illumination LEDs: 4
Infra-red wavelength: 850 nm

Video

Maximum resolution: 2688 x 1520 pixels
Total megapixels: 4 MP
Video compression formats: H.264, H.264+, H.265, H.265+
Supported graphics resolutions: 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 2688 x 1520
Feature: Video recording
Feature: Video streaming
Feature: Noise reduction
Noise reduction technology: 3D noise reduction
Image quality adjustment: Brightness, Contrast, Mirror, Saturation, Sharpness
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Bit rate: Main Stream: 256 Kbps to 6 Mbps, Sub-Stream: 512 Kbps to 1024 Kbps
Feature: Back Light Compensation (BLC)
Feature: Highlight Compensation (HLC)
Feature: Digital Wide Dynamic Range (DWDR)
Feature: Region of Interest (ROI) encoding
Feature: Smart IR

Audio

Audio system: 2-way
Audio input channels: 1.0 channels
Audio output channels: 1.0 channels
Audio formats supported: G.711 A-law
Sample rate: 8 kHz
Signal-to-Noise Ratio (SNR): 52 dB
Feature: Built-in microphone
Number of microphones: 1
Feature: Audio detection
Bit rate range: 0 - 64 Kbit/s

Network

Feature: Ethernet LAN
Networking standards: IEEE 802.3af, IEEE 802.3at
Supported network protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
Feature: Live view
Number of simultaneous live view channels: 6 channels

Storage

Feature: Card reader integrated
Compatible memory cards: MicroSD (TransFlash)
Maximum memory card size: 512 GB

Ports & interfaces

Ethernet LAN (RJ-45) ports: 1
Feature: DC-in jack

Security

Alarm input channels: 1
Alarm output channels: 1
Feature: Built-in siren
Feature: Password protection
Feature: Video motion detection
Feature: IP address filtering
Feature: HTTPS encryption
Alert notification type: Push notification
Feature: Motion sensor
Feature: Mirror
Feature: Human and vehicle targets classification
Feature: Digest authentication

Management features

Feature: Web-based management
Feature: Web browser
Feature: Cloud-managed
Feature: Reset button

Power

Power source type: DC, PoE
Power consumption (max): 10.8 W
Power consumption (Power over Ethernet (PoE)): 12 W
DC output voltage: 12

Operational conditions

Operating temperature (T-T): -30 - 60 °C
Storage temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%

Weight & dimensions

Width: 100 mm
Height: 101 mm
Length: 256 mm
Weight: 1.04 kg

Packaging data

Package type: Box

Packaging content

Number of cameras: 1
