TP-Link TL-WN722N network card

TP-Link TL-WN722N. Connectivity technology: Wireless, Host interface: USB, Interface: WLAN. Maximum data transfer rate: 150 Mbit/s, Top Wi-Fi standard: Wi-Fi 4 (802.11n), Wi-Fi band: Single-band (2.4 GHz). Product colour: Black, White

WHAT THIS PRODUCT DOES
The TP-LINK TL-WN722N Wireless High Gain USB Adapter allows you to connect a desktop or notebook computer to a wireless network and access high-speed Internet connection. Using AlignTM 1-stream technology based on 802.11n technology, TL-WN722N provides a better wireless signal than existing wireless 802.11g technology. Most of all, equipped 4dBi detachable antenna can remarkably boost your signal range and speed. Now you can get a better Internet experience, such as downloading, gaming, video streaming and so on.

HIGH GAIN DESIGN
With powerful 4dBi detachable antenna, the TL-WN722N remains excellent performance in the long range and bad environment, it can receive signal from wireless base even separated by 2 floors.

QUICK SECURE SETUP
Quick Security Setup is a handy feature that allows users to almost instantly setup their security simply by pressing the QSS button on the wireless adapter, it automatically establishes a WPA secure connection, instantly protecting your network.

Features
- 150Mbps wireless transmission rate;
- Provides two methods of operation: Infrastructure and Ad-Hoc;
- Quick Secure Setup, complies with WPS for worry free wireless security;
- Supports 64/128-bit WEP, complies with 128 bit WPA standard(TKIP/AES), supports MIC, IV Expansion, Shared Key Authentication, IEEE 802.1X;
- 4dBi omni-directional antenna detachable;
- Supports Windows 2000/XP/Vista/7 OS;
- Seamlessly compatible with 802.11b/g/n devices.

Ports & interfaces

Connectivity technology: Wireless
Host interface: USB
Interface: WLAN

Network

Maximum data transfer rate: 150 Mbit/s
Networking standards: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Feature: Wi-Fi
Wi-Fi band: Single-band (2.4 GHz)
Frequency range: 2.4 - 2.4835 GHz
Top Wi-Fi standard: Wi-Fi 4 (802.11n)
Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rates supported: 11,54,150 Mbit/s
Modulation: 16-QAM, 64-QAM, CCK, DBPSK, DQPSK, OFDM
Security algorithms: 64-bit WEP, 128-bit WEP, WMM, WPA-PSK, WPA2-PSK

Design

Product colour: Black, White
Antenna: Yes
Antenna design: External
Antenna connector type: RP-SMA
Antenna direction type: Omni-directional
Antenna gain level (max): 4 dBi
Transmitting power (CE): 20 dBm
Transmitting power (FCC): 27 dBm
Feature: WPS push button
Operating modes: Infrastructure mode

System requirements

Mac operating systems supported: Yes
Linux operating systems supported: Yes

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%

Sustainability

Feature: Sustainability compliance

Weight & dimensions

Width: 93.5 mm
Depth: 26 mm
Height: 11 mm

Packaging data

Package width: 200 mm
Package depth: 150 mm
Package height: 39 mm
Package weight: 180 g

Packaging content

Cables included: USB
Feature: Resource CD
Feature: Quick installation guide

Technical details

Compliance certificates: CE, Federal Communications Commission (FCC), RoHS

Logistics data

Harmonized System (HS) code: 85176990
