TP-Link ES210X-M2 network switch

TP-Link ES210X-M2. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 8. MAC address table: 16000 entries, Switching capacity: 80 Gbit/s. Networking standards: IEEE 802.1p. Rack mounting, Form factor: Desktop/Wall-Mounting

Management features

Switch type: Managed

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
SFP+ module slots quantity: 2

Network

Networking standards: IEEE 802.1p
Feature: Port mirroring
Feature: Flow control support
Feature: Link aggregation
Feature: Broadcast storm control
Feature: Auto MDI/MDI-X

Data transmission

Switching capacity: 80 Gbit/s
Forwarding rate: 59.52 Mpps
MAC address table: 16000 entries
Feature: Store-and-forward
Feature: Jumbo frames support
Packet buffer memory: 0.64 MB

Security

DHCP features: DHCP client
Feature: IGMP snooping

Design

Feature: Rack mounting
Form factor: Desktop/Wall-Mounting
Product colour: Black
LED indicators: Yes

Performance

Feature: Firmware upgradeable

Power

Power source: DC
Feature: Power supply included

Operational conditions

Operating temperature (T-T): -5 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%

Weight & dimensions

Width: 209 mm
Depth: 126 mm
Height: 26 mm

Packaging content

Feature: Quick start guide
