Synology FS6400 NAS / storage server

Synology FS6400. Chassis type: Rack (2U). Processor family: Intel® Xeon®, Processor model: 4110, Processor frequency: 2.1 GHz. Internal memory: 32 GB, Internal memory type: DDR4-SDRAM. Operating system installed: Windows Server 2016 Standard

Uncompromising performance
Synology FlashStation FS6400 is a 2U rackmount server designed for I/O-intensive and latency-sensitive tasks, ideal for multimedia post-production, virtual machines, online transaction processing, or database applications.

Fast and reliable networking
With multi-LAN design, FS6400 is capable of performing Link Aggregation and failover. For environments requiring a higher speed, two optional Ethernet add-in cards can be installed on PCIe 3.0 slots to provide fast data transmission.

Complete iSCSI and virtualization solutions
Synology iSCSI storage supports most virtualization solutions such as VMware vSphere, Microsoft Hyper-V, Citrix Xen Server, and OpenStack Cinder to enhance work efficiency. You can run and manage multiple virtual machines on Windows, Linux, or DSM using Virtual Machine Manager.

Next-generation file system for better data protection
The Btrfs file system introduces advanced storage technologies and optimized snapshots to prevent data corruption and reduce maintenance overheads. It offers flexible, efficient data protection and recovery tools while ensuring high-level data integrity.

Flexible Shared Folder/User Quota System provides comprehensive quota control on all user accounts and shared folders

Snapshot Replication provides schedulable and storage capacity-saving data protection with 1,024 shared folder backups and 65,000 system-wide snapshots

File- or folder-level data restoration accelerates data recovery and provides more flexibility for businesses

Automatic file self-healing detects and recovers corrupted files without user intervention

RAID F1
Due to the peculiarities of SSD and RAID technology, a common challenge lies in how to prevent all of the drives from failing at the same time because of the evenly distributed workload. RAID F1 alleviates this problem with a specially designed algorithm to unevenly distribute workload to drives, enhancing the resilience of the storage pool and ensuring your data remains safe.

Digital asset protection
Powered by Synology DiskStation Manager (DSM), Synology NAS offers advanced security measures to protect against sudden data loss and potential security holes. Learn more

Security Advisor
Analyze system settings, password strength and network preferences, and remove any possible malware.

AppArmor
A kernel-level enhancement that blocks malicious programs from accessing unauthorized system resources.

AES 256-bit encryption
ncrypt shared folders and network data transmission to avoid unauthorized data access.

2-step verification
Prevent others from logging in to your DSM by generating a six-digit one-time password (OTP) on your mobile device.

Trust level
Customize the trust level in Package Center to avoid installing packages from untrusted sources, safeguarding your NAS from unknown or tampered package files.

5-year warranty
As we're committed to improving product innovation and quality, Synology guarantees a robust and reliable data management experience with a 5-year limited warranty, providing responsive technical support and hardware replacement services to maximize your return on investment.

Synology Replacement Service (SRS)
SRS provides free advance replacement units as early as the next business day in selected regions, maximizing the service uptime for your mission-critical storage and ensuring your business continuity.

Powered by Synology DSM

Synology High Availability
Seamless transition between clustered servers in the event of a server failure to minimize the impact on applications.

Synology Office
Collaborate on documents, spreadsheets, and slides in real time to boost team productivity.

Synology MailPlus
Secure, reliable, and private mail server solution with an intuitive and modern mail client.

Virtual Machine Manager
Run various operating systems in isolated sandboxes. Seamlessly clone, restore and migrate virtual machines.

Security
Comprehensive built-in security tools are constantly updated to protect your devices against evolving threats.

Snapshot Replication
Schedulable and instantaneous data protection for shared folders and iSCSI LUNs for disaster prevention.

Storage

Feature: RAID support
RAID levels: 0, 1, 5, 6, 10, JBOD
Feature: Storage drives installed

Processor

Processor manufacturer: Intel
Processor generation: 1st Generation Intel® Xeon® Scalable
Processor family: Intel® Xeon®
Processor model: 4110
Processor frequency: 2.1 GHz
Processor boost frequency: 3 GHz
Processor cores: 8
Processor threads: 16
Processor cache: 11 MB
Number of processors installed: 2
PCI Express slots version: 3.0
Processor cache type: L3
Processor codename: Skylake
Processor lithography: 14 nm
Processor operating modes: 64-bit
Processor package size: 76.0 x 56.5 mm
Processor socket: LGA 3647 (Socket P)
Scalability: 2S
Tcase: 77 °C
Thermal Design Power (TDP): 85 W
Maximum internal memory supported by processor: 768 GB
Feature: Conflict-Free processor

Memory

Internal memory: 32 GB
Internal memory type: DDR4-SDRAM
Memory slots: 16

Network

Feature: Ethernet LAN
Feature: Wake-on-LAN ready
Supported network protocols: CIFS, AFP, NFS, FTP, WebDAV
Cabling technology: 10/100/1000Base-T(X)

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Ethernet LAN (RJ-45) ports: 2
PCI Express x8 (Gen 3.x) slots: 2

Design

Chassis type: Rack (2U)
Product colour: Black

Performance

Number of users: 6000 user(s)
Noise level: 53.7 dB
Optical drive type: No

Software

Operating system installed: Windows Server 2016 Standard

Power

Number of power supply units: 1
Feature: Redundant power supply (RPS) support
Power consumption (typical): 288.49 W

Weight & dimensions

Width: 482 mm
Depth: 724 mm
Height: 88 mm
Weight: 17.3 kg

Packaging content

Cables included: AC

Processor special features

Feature: Embedded options available
Feature: Enhanced Intel SpeedStep Technology
Feature: Execute Disable Bit
Feature: Intel 64
Feature: Intel Trusted Execution Technology
Feature: Intel TSX-NI
Intel TSX-NI version: 1.00
Feature: Intel Virtualization Technology (VT-x)
Feature: Intel Virtualization Technology for Directed I/O (VT-d)
Feature: Intel VT-x with Extended Page Tables (EPT)
Feature: Intel® AES New Instructions (Intel® AES-NI)
Feature: Intel® Hyper Threading Technology (Intel® HT Technology)
Intel® Turbo Boost Technology: 2.0
Maximum number of PCI Express lanes: 48
Memory types supported by processor: LPDDR4-SDRAM

Operational conditions

Operating temperature (T-T): 0 - 35 °C
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -20 - 60 °C

Logistics data

Harmonized System (HS) code: 84714100

Other features

Power requirements: 100 - 240
Compatible operating systems: Windows Server 2016
Maximum internal memory: 512000 MB
Power consumption (standby): 145.8 W
Certification: EAC, VCCI, RCM, KC, FCC, CE, BSMI
Processor ARK ID: 123547
