Synology DiskStation DS2422+ NAS / storage server

Synology DiskStation DS2422+. Type: NAS. Chassis type: Tower. Device class: Small & Medium Business. Processor family: Ryzen Embedded, Processor model: V1500B, Processor frequency: 2.2 GHz. Internal memory: 4 GB, Internal memory type: DDR4. Total installed storage capacity: 0 TB. Operating system installed: DiskStation Manager

Built for high-performance mass storage
The 12-bay Synology DiskStation DS2422+ is a capable choice for small and medium businesses with large storage, file sharing, and data protection requirements in a multi-user environment. It comes with powerful storage management, file syncing, surveillance, and backup software, and is suitable for editing high-quality video and as VM storage.

Faster performance
Comfortably run demanding applications and processes with multiple users on the DS2422+ while still enjoying a smooth and fast experience. See the improvements that help make your business productive.

Rise to the challenge
Prepare your DS2422+ for heavy workloads or upgrade flexibly as your business continues to grow. Use add-in cards to add bandwidth, fast SSD cache, or both.

Ready for remote work
Empower your workforce to collaborate, share files, and communicate from anywhere.

Certified virtual machine storage
DSM streamlines provisioning for and management of virtual machines with full certification for VMware® vSphere™, Microsoft® Hyper-V®, Citrix® XenServer™, and OpenStack virtualization environments.

Synology Storage Console for VMware® or Windows platforms lets you manage storage directly from your hypervisor. VMware® VAAI integration and Windows ODX help offload storage operations and speed up data transfer, and a Kubernetes CSI driver lets you provision and manage volumes directly from the K8s CLI.

Storage

Storage drive capacity: 0 GB
Supported storage drive interfaces: Serial ATA, Serial ATA II, Serial ATA III
Storage drive sizes supported: 2.5,3.5"
Maximum supported storage capacity: 108 TB
Feature: RAID support
RAID levels: 0, 5, 6, 10, JBOD
Feature: Hot-swap drive bays
Supported file systems: BTRFS, Fat, HFS+, NTFS, ext3, ext4
Total installed storage capacity: 0 TB
Number of storage drives supported: 12
Installed storage drive type: No
Supported storage drive types: HDD & SSD

Processor

Processor manufacturer: AMD
Processor generation: AMD Ryzen Embedded V1000 Series
Processor family: Ryzen Embedded
Processor model: V1500B
Processor frequency: 2.2 GHz
Processor cores: 4
Number of processors supported: 1

Memory

Internal memory: 4 GB
Internal memory type: DDR4
Maximum RAM supported: 32 GB
Memory slots: 2
Memory form factor: SO-DIMM
Feature: ECC

Network

Feature: Ethernet LAN
Ethernet LAN data rates: 1000 Mbit/s
Feature: Wake-on-LAN ready
Supported network protocols: SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Feature: Link aggregation

Ports & interfaces

Feature: USB port
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Ethernet LAN (RJ-45) ports: 4
PCI Express x8 (Gen 3.x) slots: 1

Design

Chassis type: Tower
Cooling type: Active
Product colour: Black
Number of fans: 2 fan(s)
Fan diameter: 12 cm
Fan diameter 2: 12 cm
Feature: Drive bay locking

Performance

Type: NAS
Device class: Small & Medium Business
Feature: Backup function
Backup features: Cloud, iSCSI LUN
Feature: Multilingual support
Noise level: 25 dB
Feature: Web-based management
Feature: Access Control List (ACL)
Browser supported: Chrome, Firefox, Edge, Internet Explorer, Safari

Software

Operating system installed: DiskStation Manager

Power

Power supply location: Built-in
Power supply unit (PSU) capacity: 550 W
Number of power supply units: 1
Power consumption (typical): 73.11 W
Power consumption (HDD standby): 32.12 W
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz

Weight & dimensions

Width: 300 mm
Depth: 340 mm
Height: 270 mm
Weight: 9.5 kg

Packaging content

Cables included: AC, LAN (RJ-45)

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -20 - 60 °C
Storage relative humidity (H-H): 5 - 95%

Logistics data

Harmonized System (HS) code: 84714100

Other features

Compliance certificates: RoHS
Certification: FCCCEBSMIVCCIRCMUKCAEACCCCKCUL
