Synology DiskStation DS224+ NAS / storage server

Synology DiskStation DS224+. Type: NAS. Chassis type: Desktop. Device class: Home & Home Office. Processor family: Intel® Celeron®, Processor model: J4125, Processor frequency: 2 GHz. Internal memory: 2 GB, Internal memory type: DDR4. Total installed storage capacity: 0 TB

DiskStation DS224+
Compact data storage for edge deployments

Consolidate and safeguard
Protect all your data with integrated security features and centralized access.

Manage important data
Share, back up, and access files, photos, surveillance video, and more.

Minimize energy impact
15 watts under full operation keeps operating costs low.

Simply faster
DS224+ is faster at indexing files in Synology Drive and Synology Photos and more capable of running demanding web applications compared to previous-generation systems.1

Store, share, and protect
Manage all your documents, images, and other files, back up applications and devices, and protect your property with professional video surveillance.

Private cloud for data sharing
Hybrid work in the private cloud
Store, sync, access, and share data from any device, wherever you are. Work together seamlessly across different platforms, accessing files through mobile apps, desktop clients, or a browser-based interface. Quickly and easily roll back files in case of unwanted deletion or modification thanks to smart versioning.

Multi-layered backup
Back up workstations, smartphones, cloud apps, and more
Consolidate and automate backup tasks for workstations, file servers, VMs, SaaS applications, and more with Active Backup Suite. Administer device backups remotely through a centralized portal and quickly restore specific files or entire devices to keep your business up and running. Take advantage of built-in remote backup solutions designed to protect your data with seamless 3-2-1 backup configurations.

Smart surveillance management
Synology Surveillance Station
Protecting your business has never been easier, with centralized management, support for over 8,300 IP camera models, and remote monitoring and playback. Synology's video management system provides all the tools you need for live monitoring, investigation, management, and backup.3

Btrfs: advanced file system for data protection
The Synology DiskStation Manager (DSM) operating system that powers the DS224+ uses the advanced Btrfs file system, which safeguards your data against corruption and allows for the reversal of unintended or malicious changes through the use of snapshot technology.

Performance backed by Synology drives
Leverage high sustained performance and reliability with well-engineered drives designed specially for Synology systems.4

Storage

Storage drive capacity: 0 GB
Storage drive interface: Serial ATA
Storage drive size: 2.5/3.5"
Feature: RAID support
RAID levels: 0, 1, JBOD
Supported file systems: BTRFS, Fat, HFS+, NTFS, exFAT, ext3, ext4
Total installed storage capacity: 0 TB
Number of storage drives supported: 2
Installed storage drive type: No
Supported storage drive types: HDD & SSD

Processor

Processor manufacturer: Intel
Processor family: Intel® Celeron®
Processor model: J4125
Processor frequency: 2 GHz
Processor boost frequency: 2.7 GHz
Processor cores: 4
CPU configuration (max): 1

Memory

Internal memory: 2 GB
Internal memory type: DDR4
Maximum RAM supported: 6 GB

Network

Feature: Ethernet LAN
Feature: iSCSI support
Feature: Wake-on-LAN ready
Supported network protocols: SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV

Ports & interfaces

Feature: USB port
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Ethernet LAN (RJ-45) ports: 2

Design

Chassis type: Desktop
Cooling type: Active
Product colour: Black
Number of fans: 1 fan(s)
Fan diameter: 9.2 cm
LED indicators: Yes

Performance

Type: NAS
Device class: Home & Home Office
Feature: Backup function
Number of users: 1200 user(s)
Noise level: 22 dB
Feature: Access Control List (ACL)
Feature: On/off switch
Browser supported: Google Chrome, Firefox, Microsoft Edge, Safari
Feature: USB copy function

Power

Power supply unit (PSU) capacity: 60 W
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz

Weight & dimensions

Width: 108 mm
Depth: 232.2 mm
Height: 165 mm
Weight: 1.3 kg

Packaging content

Feature: External power adapter
Cables included: AC, LAN (RJ-45)

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -20 - 60 °C
