Switch - Zyxel GS1920-24HPV2, Power over Ethernet (PoE), Black
Product reference:
14-4718937601936
The Zyxel GS1920-24HPV2 is a powerful Ethernet switch with 24 gigabit ports and a 375W PoE budget, ensuring fast and efficient network management.
Switch - Zyxel GS1920-24HPV2, Power over Ethernet (PoE), Black
Product reference:
14-4718937601936
The Zyxel GS1920-24HPV2 is a powerful Ethernet switch with 24 gigabit ports and a 375W PoE budget, ensuring fast and efficient network management.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 9
business days
Ethernet switch - Zyxel GS1920-24HPv2, Black
The Zyxel GS1920-24HPV2 is a high-performance Ethernet switch that supports a variety of IEEE standards and features. It uses copper Ethernet cabling technology with 100BASE-TX and 1000BASE-T speeds.
Main features:
- Supports IEEE standards including 802.1x, 802.3ab, and 802.3ad
- 24 Gigabit Ethernet (10/100/1000) ports and 4 Combo SFP ports
- Total Power over Ethernet (PoE) budget: 375 W with 24 PoE ports
- Connection capacity: 56 Gbit/s, packet buffer memory: 1.5 MB
Design | |
|---|---|
| Product color | Black |
| LED indicators | Yes |
| Electromagnetic compatibility | FCC 15 A, CE A, BSMI EMC |
| Security | LVD, BSMI |
| Rack mounting | Yes |
Electricity | |
| AC input voltage | 100 - 240V |
| Power (max) | 463.5W |
| AC input frequency | 50 - 60 Hz |
Security | |
| Access Control List (ACL) | Yes |
| DHCP functions | DHCPv6 relay, DHCP client, DHCP relay, DHCP snooping |
| Processor protection | Yes |
| Password protection | Yes |
| Security algorithms | SNMP, 802.1x RADIUS, SNMPv3 |
| MAC address filtering | Yes |
| Authentication type | IEEE 802.1x, RADIUS |
| IP-MAC-Port binding | Yes |
| Step-by-step scheduling algorithms | WFQ, SPQ, Weighted Round Robin (WRR) |
| Authentication | Guest VLAN, Port-based authentication |
| IGMP snooping | Yes |
Operating conditions | |
| Heat release | 1580.54 BTU/h |
| Operating temperature (OT) | 0 - 50 °C |
| Storage relative humidity (HH) | 10 - 95% |
| Operating relative humidity (HH) | 10 - 95% |
| Storage temperature (TT) | -40 - 70 °C |
Control functions | |
| Switch type | Managed |
| System event log | Yes |
| Quality of Service (QoS) support | Yes |
| ARP inspection | Yes |
Weight and dimensions | |
| Depth | 270mm |
| Weight | 3.8 kg |
| Height | 44 mm |
| Width | 441 mm |
Network | |
| Network standards | IEEE 802.3at, IEEE 802.3af, IEEE 802.1w, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1x, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1D, IEEE 802.3z, IEEE 802.1ab, IEEE 802.3u |
| Copper Ethernet cable technology | 100BASE-TX, 1000BASE-T |
| Speed limit | Yes |
| Spanning tree protocol | Yes |
| VLAN support | Yes |
| Virtual LAN features | Voice VLAN, Port-based VLAN, MAC address-based VLAN, Private VLAN, Protocol-based VLAN, IP subnet-based VLAN |
| 10G support | No |
| Data flow control support | Yes |
Performance | |
| Mean Time Between Failures (MTBF) | 638691 hours |
| Noise level | 27.2 dB |
| Flash memory | 32MB |
| Internal memory | 256MB |
Packaging details | |
| Package width | 616 mm |
| Package height | 107 mm |
| Package depth | 355mm |
| Cables included | AC |
| Package weight | 4.97 kg |
| Rack mounting kit | Yes |
Ports and interfaces | |
| Number of main RJ-45 Ethernet ports | 24 |
| Combo SFP ports quantity | 4 |
| Type of main RJ-45 Ethernet ports | Gigabit Ethernet (10/100/1000) |
| Fiber optic switch | SFP |
| | |
Data transfer | |
| MAC address table | 16000 entries |
| Connection capacity | 56 Gbps |
| Packet buffer memory | 1.5MB |
| Transmission speed | 42 Mpps |
Power over Ethernet (PoE) | |
| Full Power over Ethernet (PoE) budget | 375W |
| Power over Ethernet (PoE) ports quantity | 24 |
| Power over Ethernet (PoE) | Yes |
Multicast functions | |
| Multicast support | Yes |
Fiber optics | |
| Fiber Ethernet Cable Technology | 1000Base-X |
