Switch, UBIQUITI, USW-PRO-48, Type L3, Rack, 48x10Base-T / 100Base-TX / 1000Base-T, 4xSFP+, USW-PRO-48
Product reference:
2-810010070616
Switch, UBIQUITI, USW-PRO-48, Type L3, Rack, 48x10Base-T / 100Base-TX / 1000Base-T, 4xSFP+, USW-PRO-48
Product reference:
2-810010070616
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
12 month
Delivery from Lithuania in
3 - 5
business days
UniFi Switch Pro 48 is a fully managed Layer 3 switch with (48) Gigabit Ethernet ports. (4) 10G SFP+ uplinks offer link aggregation for higher capacity and increased availability.
The UniFi Switch Pro 48 features a rich set of Layer 2 capabilities and integrates Layer 3 functionality such as inter-VLAN routing, static routing, and DHCP server. The UniFi Switch Pro 48 is an ideal aggregation and access layer switch for any UniFi solution - it combines innovative near-silent cooling with UniFi SmartPower RPS power redundancy. UniFi Network Controller and UniFi Network mobile app allow admins to configure and monitor virtually all of the switch features in an intuitive graphical user interface from anywhere.
- (48) Gigabit RJ45 ports
- (4) 10G SFP+ ports
- Layer 2 and Layer 3 features
- UniFi SmartPower RPS DC input
- Near-silent cooling
- 1.3" touchscreen display
- Managed by UniFi Network Controller
| 10G support | Yes |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Authentication type | IEEE 802.1x,RADIUS |
| Backlight display | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 48 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Broadcast storm control | Yes |
| Certification | CE, FCC, IC ETSI300-019-1.4 |
| DC input voltage | 11.5 V |
| Depth | 285.4 mm |
| Flow control support | Yes |
| Form factor | 1U |
| Forwarding rate | 130.944 Mpps |
| Harmonized System (HS) code | 85176990 |
| Height | 43.7 mm |
| Input current | 5.22 A |
| LED indicators | Activity/Link/Speed |
| Link aggregation | Yes |
| Model name | USW-PRO-48 |
| Networking standards | IEEE 802.1x |
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | -5 - 45 °C |
| Port mirroring | Yes |
| Power consumption (max) | 60 W |
| Power over Ethernet (PoE) | No |
| Power supply included | Yes |
| Product colour | Silver |
| Product Net Weight | 4.09 kg |
| Rack mounting | Yes |
| SFP+ module slots quantity | 4 |
| Shipping Box Depth | 52.3 cm |
| Shipping Box Height | 39.5 cm |
| Shipping Box Weight | 5.2 kg |
| Shipping Box Width | 12.2 cm |
| Spanning tree protocol | Yes |
| Summary | Ubiquiti UniFi USW-PRO-48. Switch type: Managed, Switch layer: L2/L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 48. Switching capacity: 176 Gbit/s. Networking standards: IEEE 802.1x. DC input voltage: 11.5 V. Rack mounting, Form factor: 1U |
| Switch layer | L2/L3 |
| Switch type | Managed |
| Switching capacity | 176 Gbit/s |
| Unit Box Height | 0.395 |
| Unit Box Length | 0.523 |
| Unit Box Width | 0.122 |
| Unit Calculated Volume | 0.0252 cubm |
| Unit Calculated Weight | 5.2 kg |
| Units per Shipping Box | 1 |
| User guide | Yes |
| Vendor Homepage | https://store.ui.com/collections/unifi-network-routing-switching/products/usw-pro-48 |
| VLAN support | Yes |
| Weight | 4000 g |
| Width | 442.4 mm |
