Switch - Ubiquiti Pro Max 48 L3 2.5G 1U Gray
Product reference:
14-810084692745
This switch with 16 x 2.5G and 32 x Gigabit Ethernet ports ensures high performance and supports VLAN, IEEE 802.1x standards and jumbo frames up to 9KB, making it perfect for complex network structures.
Switch - Ubiquiti Pro Max 48 L3 2.5G 1U Gray
Product reference:
14-810084692745
This switch with 16 x 2.5G and 32 x Gigabit Ethernet ports ensures high performance and supports VLAN, IEEE 802.1x standards and jumbo frames up to 9KB, making it perfect for complex network structures.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 9
business days
Ubiquiti Pro Max 48 2.5G Ethernet Switch Gray
Ubiquiti Pro Max 48 L3 2.5G Ethernet switch is a compact and high-performance device designed for reliable networking applications.
Main features:
- L3 connection layer
- 16 x 2.5G Ethernet ports (100/1000/2500)
- 4 x SFP+ module slots
- Supports VLAN, voice VLAN, traffic limiting, broadcast storm control, and port mirroring
Technical data | |
|---|---|
| Certificates of conformity | Industry Canada (IC), FCC, CE |
Design | |
| Can be mounted one on top of the other | Yes |
| Reset button | Yes |
| Housing | SGCC |
| Rack mounting | Yes |
| Form | 1U |
| LED indicators | Speed, Connection, Status, Network |
| Display type | LCM |
| Product color | Gray |
Power | |
| AC input frequency | 50/60Hz |
| Redundant power supply support | Yes |
| Maximum power consumption | 100W |
| Power supply included | Yes |
| Power source | AC/DC |
| AC input voltage | 100 - 240V |
Security | |
| Loop protection | Yes |
| IGMP snooping | Yes |
| DHCP functions | DHCP relay, DHCP monitoring |
Operating conditions | |
| Operating relative humidity | 10 - 90% |
| Operating temperature | -5 - 40 °C |
Control functions | |
| Switch layer | L3 |
Weight and dimensions | |
| Height | 43.7 mm |
| Weight | 4.8 kg |
| Depth | 325mm |
| Width | 442.4 mm |
Network | |
| Virtual LAN features | Voice VLAN |
| Flow limiting | Yes |
| Broadcast storm control | Yes |
| Port mirroring support | Yes |
| Flow control support | Yes |
| VLAN support | Yes |
| Network standards | IEEE 802.1x |
| 10G support | Yes |
Packaging details | |
| Mounting brackets included | Yes |
| Cables included | Power supply |
Ports and interfaces | |
| 2.5G Number of Ethernet ports | 16 |
| Number of SFP+ module slots | 4 |
| Number of Gigabit Ethernet ports | 32 |
| Power connector | AC/DC |
| Main types of Ethernet ports | 2.5G Ethernet (100/1000/2500) |
| Number of main RJ-45 Ethernet ports | 48 |
Data transfer | |
| Transmission speed | 166.656 Mpps |
| Static route | Yes |
| Throughput | 112 Gbps |
| Connection capacity | 224 Gbps |
| Jumbo frame support | Yes |
Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Height | 520mm |
| Length | 430 mm |
| Weight | 6060 grams |
| Width | 120mm |
