Ideal for Surveillance
TL-SG1218MPE complies with the 802.3af/at PoE+ standard, supporting up to 30W power supply on each PoE port. The total high PoE power budget is up to 192W for the 16 PoE ports, making it ideal for small to medium business surveillance systems.
Intelligent Power Management
When total power consumption excels 192W, the intelligent power management will cut the lower priority port power off to ensure the high priority port's power supply and protect the device from power overload operation.
Making Management Easy
TL-SG1218MPE offers network monitoring for users to observe traffic behavior. Through its web-based user interface and management utility, the TL-SG1218MPE offers a variety of useful features, including network monitoring, traffic prioritization, and enhanced QoS.
| 10G support | No |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Auto MDI/MDI-X | Yes |
| Auto-negotiation | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Broadcast storm control | Yes |
| Cable types supported | Cat3/Cat4/Cat5/Cat5e/Cat6 |
| Cables included | AC |
| Certification | CE, FCC, RoHS |
| Copper ethernet cabling technology | 1000BASE-T/100BASE-TX/10BASE-T |
| Depth | 180 mm |
| Fiber ethernet cabling technology | 1000BASE-X |
| Flow control support | Yes |
| Form factor | 1U |
| Forwarding rate | 23.8 Mpps |
| Gigabit Ethernet (copper) ports quantity | 16 |
| Harmonized System (HS) code | 85176990 |
| Heat dissipation | 741.15 BTU/h |
| Height | 44 mm |
| IGMP snooping | Yes |
| Jumbo frames | 9000 |
| Jumbo frames support | Yes |
| Link aggregation | Yes |
| Loop protection | Yes |
| MAC address table | 8000 entries |
| Model name | JetStream 16-Port Gigabit Easy Smart PoE/PoE+ Switch |
| Networking standards | IEEE 802.1p/IEEE 802.1Q/IEEE 802.3/IEEE 802.3ab/IEEE 802.3af/IEEE 802.3at/IEEE 802.3u/IEEE 802.3x |
| Number of fans | 2 fan(s) |
| Number of queues | 4 |
| Number of VLANs | 32 |
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | 0 - 50 °C |
| Package depth | 528 mm |
| Package height | 80 mm |
| Package weight | 2910 g |
| Package width | 250 mm |
| Packet buffer memory | 4.1 MB |
| Port mirroring | Yes |
| Power consumption (max) | 217.22 W |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 16 |
| Power source | AC |
| Power supply included | Yes |
| Product colour | Black |
| Product Net Weight | 3 kg |
| Quality of Service (QoS) support | Yes |
| Rack mount kit | Yes |
| Rack mounting | Yes |
| Rate limiting | Yes |
| Security algorithms | SNMP/SNMPv2/SNMPv3 |
| SFP module slots quantity | 2 |
| Shipping Box Depth | 53 cm |
| Shipping Box Height | 8 cm |
| Shipping Box Weight | 3.11 kg |
| Shipping Box Width | 25 cm |
| Storage relative humidity (H-H) | 5 - 90 % |
| Storage temperature (T-T) | -40 - 70 °C |
| Store-and-forward | Yes |
| Summary | TP-Link JetStream 16-Port Gigabit Easy Smart PoE/PoE+ Switch. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 16. MAC address table: 8000 entries, Switching capacity: 36 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE.... Power over Ethernet (PoE). Rack mounting, Form factor: 1U |
| Switch layer | L2 |
| Switch type | Managed |
| Switching capacity | 36 Gbit/s |
| Total Power over Ethernet (PoE) budget | 192 W |
| Unit Box Height | 0.08 |
| Unit Box Length | 0.53 |
| Unit Box Width | 0.25 |
| Unit Calculated Volume | 0.0106 cubm |
| Unit Calculated Weight | 3.11 kg |
| Units per Shipping Box | 1 |
| User guide | Yes |
| Vendor Homepage | https://www.tp-link.com/ae/business-networking/easy-smart-switch/tl-sg1218mpe/ |
| Virtual LAN features | Port-based VLAN |
| VLAN support | Yes |
| Web-based management | Yes |
| Width | 440 mm |
