Switch - TP-Link Omada 28-Port Gigabit Smart Switch 16-Port PoE+
Product reference:
14-8885020620832
TP-Link Omada 28-Port Gigabit Smart Switch with 16 PoE+ ports and a total PoE budget of 150W. It is a managed switch with a web-based management interface, VLAN support, and 56 Gbit/s switching capacity.
Switch - TP-Link Omada 28-Port Gigabit Smart Switch 16-Port PoE+
Product reference:
14-8885020620832
TP-Link Omada 28-Port Gigabit Smart Switch with 16 PoE+ ports and a total PoE budget of 150W. It is a managed switch with a web-based management interface, VLAN support, and 56 Gbit/s switching capacity.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 9
business days
TP-Link Omada 28-Port Gigabit Smart Switch With 16 PoE+ Ports
28-port Gigabit smart switch with 16 PoE+ ports and a total PoE budget of 150 W. Managed switch with web-based management system, VLAN support, and 56 Gbit/s switching capacity.
- 28-port Gigabit Smart Switch with 16 PoE+ ports for versatile connectivity.
- Managed switch with cloud management and online configuration for easy administration.
- Robust security features including IGMP snooping, MAC address filtering, and Access Control List (ACL).
- Fanless design for quiet operation, ideal for office environments.
Design | |
|---|---|
| Rack mounting | Yes |
| Product color | Gray |
| LED indicators | Yes |
Power | |
| AC input voltage | 100 - 240V |
| Power | AC/PoE |
| Maximum energy consumption | 184.7 W |
| AC input frequency | 50/60Hz |
Security | |
| IGMP snooping | Yes |
| MAC address filtering | Yes |
| Password protection | Yes |
| DHCP functions | DHCP relay, DHCP server |
| Access Control List (ACL) | Yes |
Operating conditions | |
| Storage relative humidity (HH) | 5 - 90% |
| Heat dissipation | 628 BTU/h |
| Operating temperature (OT) | 0 - 40 °C |
| Operating relative humidity (HH) | 10 - 90% |
| Storage temperature (TT) | -40 - 70 °C |
Control functions | |
| ARP inspection | Yes |
| Online management | Yes |
| Switch type | Managed |
| Switch layer | L2/L2+ |
| Cloud management | Yes |
| Quality of Service (QoS) support | Yes |
Weight and dimensions | |
| Height | 44 mm |
| Width | 440mm |
| Depth | 220mm |
Network | |
| Link aggregation | Yes |
| Network standards | IEEE 802.3at, IEEE 802.3af |
| Spanning tree protocol | Yes |
| Automatic tuning | Yes |
| Number of VLANs | 4000 |
| Virtual LAN features | Tagged VLAN, MAC address-based VLAN, Protocol-based VLAN, Voice VLAN |
| 10G support | No |
| VLAN support | Yes |
| Data flow control support | Yes |
Operation | |
| Fanless | Yes |
Ports and interfaces | |
| Number of SFP module slots | 4 |
| Main types of RJ-45 Ethernet ports | Gigabit Ethernet (10/100/1000) |
| Number of main RJ-45 Ethernet ports | 24 |
Data transfer | |
| Transmission speed | 41.66 Mpps |
| Packet buffer memory | 4.1MB |
| Jumbo frame support | Yes |
| Jumbo frames | 9000 |
| MAC address table | 8000 entries |
| Switching capacity | 56 Gbps |
Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Yes |
| Number of Power over Ethernet plus (PoE+) ports | 16 |
| Total Power over Ethernet (PoE) budget | 150W |
| Power over Ethernet (PoE) per port | 30W |
Multicast functions | |
| Multicast support | Yes |
| Height | 100mm |
| Length | 300mm |
| Weight | 3900 grams |
| Width | 500mm |
