Switch, TP-LINK, LS109P, PoE+ ports 8, LS109P
Product reference: 2-4895252504620

Switch, TP-LINK, LS109P, PoE+ ports 8, LS109P

Product reference: 2-4895252504620
You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
27,38
Product in warehouse

Guarantee
36 month

Delivery from Lithuania in
3 - 5
business days

Your message has been successfully sent!
Fill in the required fields*
Not available

Switch de sobremesa de 9 puertos a 10/100 Mbps con 8 puertos PoE+

- 63 W de potencia PoE. 8 puertos PoE+ Gigabit compatibles con 802.3af/at alimentan fácilmente dispositivos como cámaras IP, puntos de acceso y teléfonos IP a través de un único cable. Cada puerto PoE admite hasta 30 W de salida.
- Hasta 250 m de transmisión PoE. Con el modo de extensión, la distancia de transmisión PoE alcanza hasta 250 m, ideal para el despliegue de cámaras de vigilancia en grandes áreas.
- Recuperación automática PoE. Reinicia automáticamente los dispositivos alimentados por PoE que no respondan.
- Separación de tráfico. El modo de aislamiento permite separar el tráfico de clientes con un solo clic para evitar el snooping y tampering, además de aislar el broadcast storm.
- Plug and Play. Conectividad instantánea sin necesidad de configuración.
- Funcionamiento silencioso. El diseño sin ventilador reduce el consumo de energía y garantiza un funcionamiento silencioso, ideal para hogares o empresas.
- Hardware fiable. Carcasa metálica duradera y diseño para montaje en sobremesa o pared adaptado a distintos entornos.

Alimentación a Través de Ethernet, Despliegue a Medida
Cumple con el estándar 802.3af/at PoE+, 61 W disponibles para todos los puertos PoE+, 30 W máx. por puerto.

Transmisiones de Hasta 250 m

Seguridad y Estabilidad en tu Red

Modo Aislamiento
Divide fácilmente el tráfico para evitar el snooping/tampering y broadcast storm.

Recuperación Automática PoE
Detecta y reinicia automáticamente los dispositivos que no responden.

  • 63 W de Potencia PoE
  • PoE+ de Largo Alcance (250 m)
  • Gestión Inteligente de Energía
  • Recuperación Automática PoE
  • Montaje de Sobremesa o en Pared
  • Plug and Play
  • Funcionamiento Silencioso
  • Carcasa de Metal

10G support No
AC input frequency 50 Hz
AC input voltage 220 V
Auto MDI/MDI-X Yes
Auto-negotiation Yes
Basic switching RJ-45 Ethernet ports quantity 9
Basic switching RJ-45 Ethernet ports type Fast Ethernet (10/100)
Cable types supported Cat3/Cat4/Cat5/Cat5e
Certification CE, FCC, RoHS
Copper ethernet cabling technology 100BASE-TX/10BASE-T
DC input voltage 53.5 V
Depth 98 mm
Fanless Yes
Flow control support Yes
Forwarding rate 1.3392 Mpps
Heat dissipation 249 BTU/h
Height 27 mm
Input current 1.31 A
Jumbo frames support Yes
LED indicators Yes
MAC address table 2000 entries
Model TP-LINK LS109P
Model name LS109P
Networking standards IEEE 802.3af/IEEE 802.3at/IEEE 802.3i/IEEE 802.3u/IEEE 802.3x
Operating relative humidity (H-H) 10 - 90 %
Operating temperature (T-T) 0 - 40 °C
Package type Box
Power consumption (max) 73.24 W
Power over Ethernet (PoE) Yes
Power over Ethernet (PoE) power per port 30 W
Power over Ethernet plus (PoE+) ports quantity 8
Power source DC/PoE
Power supply included Yes
Product colour Black
Quality of Service (QoS) support Yes
Storage relative humidity (H-H) 5 - 90 %
Storage temperature (T-T) -40 - 70 °C
Store-and-forward Yes
Summary TP-Link LiteWave LS109P. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 9. MAC address table: 2000 entries, Switching capacity: 1.8 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x. DC input voltage: 53.5 V. Power over Ethernet (PoE). Wall mountable
Switch type Unmanaged
Switching capacity 1.8 Gbit/s
Unit Box Height 0.225
Unit Box Length 0.28
Unit Box Width 0.07
Unit Calculated Volume 0.00518 cubm
Unit Calculated Weight 0.9 kg
Units per Shipping Box 12
User guide Yes
Vendor Homepage https://www.tp-link.com/es/business-networking/soho-switch-poe/ls109p/#highlights
Wall mountable Yes
Width 171 mm
