Switch, MIKROTIK, 8x10Base-T / 100Base-TX / 1000Base-T, 2xSFP+, CSS610-8P-2S+IN
Product reference: 2-4752224007216

Switch, MIKROTIK, 8x10Base-T / 100Base-TX / 1000Base-T, 2xSFP+, CSS610-8P-2S+IN

Product reference: 2-4752224007216
You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
198,73 €
Last product in warehouse

Guarantee
12 month

Delivery from Lithuania in
3 - 5
business days

Your message has been successfully sent!
Fill in the required fields*

CSS610-8P-2S+IN is one of the most well-rounded switches on the market. It is a perfect fit for the most diverse setups: from home networks and small offices to hotels, call centers and so on. The unique combination of size, features, and price offers unbelievable scalability potential.

There are two SFP+ ports for 10 Gigabit fiber connectivity and eight Gigabit Ethernet ports with 802.3af/at PoE-out.

This switch is all about nice and easy setups. The compact form-factor means easier shipping and handling, while the lightweight SwOS means easier configuration. You can even configure this switch from your web browser! It gives you all the core functionality of a managed switch, and even more: you can manage port-to-port forwarding, broadcast storm control, apply MAC filters, configure VLANs, mirror traffic, apply bandwidth limitations, and even adjust some MAC and IP header fields.

But the real blessing is the combination of SFP+ and PoE-out Ethernet ports. With this setup, you can do all kinds of things on a tight budget. CSS610 has an impressive total PoE-out budget of 140 W, so you can use even in the most intense scenarios - like hotels, conference halls, or call centers! Use the PoE-out ports to connect the IP-phones while the SFP+ ports connect your primary server to the ISP. Or power a bunch of network cameras and instantly upload the footage to the cloud. And manage a cluster of wireless access points at the same time. Also, scalability is no longer a problem. With our pricing, you can afford a switch on every floor!

Like every toolbox needs screwdrivers and pliers, every network can use a solid PoE switch.


10G support Yes
AC input frequency 50 - 60 Hz
AC input voltage 100 - 240 V
Basic switching RJ-45 Ethernet ports quantity 8
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Broadcast storm control Yes
Cables included AC
Certification EAC
Compliance certificates CE/RoHS
DC input voltage 48 - 57 V
Depth 216 mm
Fanless Yes
Flash memory 0.064 MB
Height 50 mm
Input current 2.2 A
Installed SFP+ modules quantity 2
International Protection (IP) code IP20
LED indicators Yes
MAC address filtering Yes
Mean time between failures (MTBF) 200000 h
Model CSS610-8P-2S+IN
Networking standards IEEE 802.3af/IEEE 802.3at
Operating system installed SwitchOS Lite
Power consumption (max) 162 W
Power over Ethernet (PoE) Yes
Power over Ethernet (PoE) ports quantity 8
Power over Ethernet (PoE) type supported Passive PoE
Power source AC/DC
Power supply included Yes
Processor model Marvell 88E6193X
Product colour White
Product Net Weight 0.7 kg
Rack mount kit Yes
Rack mounting Yes
Reset button Yes
Shipping Box Depth 39.5 cm
Shipping Box Height 28 cm
Shipping Box Weight 11 kg
Shipping Box Width 33.5 cm
Storage temperature (T-T) -40 - 70 °C
Summary Mikrotik CSS610-8P-2S+IN. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8, Installed SFP+ modules quantity: 2. Switching capacity: 56 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at. DC input voltage: 48 - 57 V. Power over Ethernet (PoE). Rack mounting
Sustainability compliance Yes
Switch type Managed
Switching capacity 56 Gbit/s
Total Power over Ethernet (PoE) budget 140 W
Unit Box Height 0.25
Unit Box Length 0.38
Unit Box Width 0.065
Unit Calculated Volume 0.00741 cubm
Unit Calculated Weight 2.2 kg
Unit Depth 38 cm
Unit Height 25 cm
Unit Width 6.5 cm
Units per Shipping Box 5
Vendor Homepage https://mikrotik.com/product/css610_8p_2s_in#fndtn-downloads
VLAN support Yes
Width 272 mm
