Switch, DAHUA, S3218-16ET-135, Switch type Unmanaged, Switch layer L2, Rack mounting Yes, Stackable Yes, Form factor 1U,
Product reference:
2-6923172527882
Switch, DAHUA, S3218-16ET-135, Switch type Unmanaged, Switch layer L2, Rack mounting Yes, Stackable Yes, Form factor 1U,
Product reference:
2-6923172527882
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
36 month
Delivery from Lithuania in
3 - 5
business days
18-Port Unmanaged Desktop Switch with 16-Port PoE
- 16 × RJ-45 10/100 Mbps (PoE) ports, 2 × RJ-45 10/100/1000 Mbps (combo) ports and 2 × SFP 1000 Mbps (combo) ports.
- Meets the requirements of IEEE802.3af, IEEE802.3at, Hi-PoE, and IEEE802.3bt power supply standards.
- PoE watchdog real-time monitors camera statues and automatically reboots faulty network cameras.
- Up to 250 m transmission distance.
- Supports VIP ports, prioritizing transmission for port1 to port8.
| Summary | Dahua Technology PoE S3218-16ET-135. Switch type: Unmanaged, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 16. Switching optical modules type: Gigabit Ethernet. MAC address table: 8000 entries, Switching capacity: 7.2 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt. Power over Ethernet (PoE). Rack mounting, Form factor: 1U |
| Vendor Homepage | https://transmission.dahuasecurity.com/en/product-list/Business/Switches/PoESwitchForSecurity/S3218-16ET-135 |
| Unit Box Height | 0.09 |
| Unit Box Length | 0.535 |
| Unit Box Width | 0.34 |
| Switch layer | L2 |
| Switch type | Unmanaged |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP module slots quantity | 2 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Networking standards | IEEE 802.3af/IEEE 802.3at/IEEE 802.3bt |
| Switching optical modules type | Gigabit Ethernet |
| Transmission distance (max) | 0.25 km |
| MAC address table | 8000 entries |
| Switching capacity | 7.2 Gbit/s |
| Throughput | 5.3568 Mpps |
| Form factor | 1U |
| Product colour | Black |
| Rack mounting | Yes |
| Stackable | Yes |
| AC input voltage | 100 - 240 V |
| Power source | AC |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) ports quantity | 2 |
| Total Power over Ethernet (PoE) budget | 135 W |
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | -10 - 55 °C |
| Storage relative humidity (H-H) | 5 - 95 % |
| Depth | 300 mm |
| Height | 44 mm |
| Width | 440 mm |
| Manual | Yes |
| Package depth | 412 mm |
| Package height | 110 mm |
| Package width | 527 mm |
| Model name | S3218-16ET-135 |
| Units per Shipping Box | 5 |
| Unit Calculated Volume | 0.1941 cubm |
| Unit Calculated Weight | 3.34 kg |
