Switch, DAHUA, CS4010-8GT-110, Type L2, Desktop / pedestal, 8x10Base-T / 100Base-TX / 1000Base-T, PoE ports 8, DH-CS4010
Product reference:
2-6923172571151
Switch, DAHUA, CS4010-8GT-110, Type L2, Desktop / pedestal, 8x10Base-T / 100Base-TX / 1000Base-T, PoE ports 8, DH-CS4010
Product reference:
2-6923172571151
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
36 month
Delivery from Lithuania in
3 - 5
business days
- Meets the requirements of IEEE802.3,IEEE802.3u,IEEE802.3x,IEEE802.3ab standards
- Meets the requirements of IEEE802.3af, IEEE802.3at, Hi-PoE, and IEEE802.3bt power supply standards
- Manages PoE power consumption and PoE power on/off. Supports Intelligent PoE
- A wide operating temperature range and a full metal casing that is fully-enclosed and dust-proof
| 10G support | No |
| Basic switching RJ-45 Ethernet ports quantity | 10 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Cloud-managed | Yes |
| Compliance certificates | CE |
| Copper ethernet cabling technology | 1000BASE-T/100BASE-TX/10BASE-T |
| DC input voltage | 54 V |
| Depth | 106 mm |
| DHCP features | DHCP client |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Flow control support | Yes |
| Forwarding rate | 4.17 Mpps |
| Gigabit Ethernet (copper) ports quantity | 10 |
| Height | 30 mm |
| Housing material | Metal |
| Input current | 2.22 A |
| Jumbo frames | 15000 |
| Jumbo frames support | Yes |
| LED indicators | Yes |
| MAC address table | 8000 entries |
| Model name | CS4010-8GT-110 |
| Networking standards | IEEE 802.3/IEEE 802.3ab/IEEE 802.3af/IEEE 802.3at/IEEE 802.3bt/IEEE 802.3u/IEEE 802.3x |
| Number of VLANs | 32 |
| Operating relative humidity (H-H) | 5 - 95 % |
| Operating temperature (T-T) | -10 - 55 °C |
| Package depth | 244 mm |
| Package height | 87 mm |
| Package weight | 1300 g |
| Package width | 256 mm |
| Packet buffer memory | 0.5 MB |
| Power consumption (max) | 110 W |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) ports quantity | 8 |
| Power source | DC/PoE |
| Power supply included | Yes |
| Product colour | Black |
| Product Net Weight | 0.55 kg |
| Quality of Service (QoS) support | Yes |
| Rack mounting | No |
| Redundant power supply (RPS) support | Yes |
| Reset button | Yes |
| Shipping Box Depth | 25.5 cm |
| Shipping Box Height | 9 cm |
| Shipping Box Weight | 1.28 kg |
| Shipping Box Width | 24.5 cm |
| Spanning tree protocol | Yes |
| Storage relative humidity (H-H) | 5 - 95 % |
| Storage temperature (T-T) | -40 - 70 °C |
| Summary | Dahua Technology DH-CS4010-8GT-110. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 10. MAC address table: 8000 entries, Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x. DC input voltage: 54 V. Power over Ethernet (PoE) |
| Sustainability compliance | Yes |
| Switch layer | L2 |
| Switch type | Managed |
| Switching capacity | 20 Gbit/s |
| Unit Box Height | 0.09 |
| Unit Box Length | 0.255 |
| Unit Box Width | 0.245 |
| Unit Calculated Volume | 0.005623 cubm |
| Unit Calculated Weight | 1.28 kg |
| Unit Depth | 25.5 cm |
| Unit Height | 9 cm |
| Unit Width | 24.5 cm |
| Units per Shipping Box | 1 |
| Vendor Homepage | https://www.dahuasecurity.com/products/All-Products/Transmission/Cloud-Managed-Switches/CS4010-8GT-110 |
| Virtual LAN features | Port-based VLAN |
| VLAN support | Yes |
| Web-based management | Yes |
| Weight | 550 g |
| Width | 190 mm |
