StarTech.com ST1000SPEX43 network card

StarTech.com 4-Port PCIe Gigabit Network Adapter Card - TAA. Internal. Connectivity technology: Wired, Host interface: PCI Express, Interface: Ethernet. Maximum data transfer rate: 2000 Mbit/s

Add four Gigabit Ethernet ports to a client, server or workstation through one PCI Express slot

Now you can add four separate Gigabit network ports to your client, server or workstation through just one PCI Express slot, to provide connectivity to multiple networks without draining your budget.

Reliable connectivity to multiple networks

This 4-port network card delivers powerful connectivity for your business, corporate or government office environment, with support for high-performance, 4-channel networking and a maximum throughput of up to 1000Mbps in each direction (2000 Mbps total). The network adapter card features the Realtek RTL8111H chipset, which is designed to deliver the performance and enhanced capabilities you need for reliable network connections to your server or computer.

A versatile and cost-effective solution

This versatile quad-port network card is ideal for many business applications requiring upgrades to servers or workstations, adding feature-rich Gigabit networking with four independent ports. Compatible with a broad range of operating systems, this cost-effective PCIe Gigabit NIC is suitable for many SMB and Enterprise applications such as virtualized environments that require multiple NICs (check your VM software for chipset compatibility).

The ST1000SPEX43 is backed by a StarTech.com 2-year hardware warranty and free lifetime technical support.

Ports & interfaces

Connectivity technology: Wired
Host interface: PCI Express
Interface: Ethernet
Ethernet LAN (RJ-45) ports: 4

Network

Maximum data transfer rate: 2000 Mbit/s
Networking standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Feature: Ethernet LAN
Ethernet LAN data rates: 10,1000,100 Mbit/s
Cabling technology: 10/100/1000BaseT(X)
Feature: Wake-on-LAN ready
Feature: Full duplex
Feature: Jumbo frames support

Design

Feature: Internal
Chipset: Realtek RTL8111G
LED indicators: Activity, Link

System requirements

Linux operating systems supported: Yes
Server operating systems supported: Windows Server 2003, Windows Server 2012, Windows Server 2016, Windows Server 2019

Operational conditions

Operating temperature (T-T): 0 - 55 °C
Storage temperature (T-T): -40 - 75 °C
Operating relative humidity (H-H): 5 - 95%

Weight & dimensions

Width: 120 mm
Depth: 138 mm
Height: 18 mm
Weight: 95 g

Packaging data

Package width: 145 mm
Package depth: 210 mm
Package height: 41 mm
Package weight: 184 g

Technical details

Compliance certificates: CE, RoHS

Logistics data

Harmonized System (HS) code: 85176990
Master (outer) case width: 446 mm
Master (outer) case length: 530 mm
Master (outer) case height: 338 mm
Products per master (outer) case: 50 pc(s)

Other features

Feature: Flow control support
Case colour: Yellow
