StarTech.com PEXUSB3S3GE network card

StarTech.com 3-Port PCI Express USB 3.0 Card + Gigabit Ethernet - 5Gbps - TAA. Internal. Connectivity technology: Wired, Host interface: PCI Express, Interface: Ethernet. Maximum data transfer rate: 5000 Mbit/s. Product colour: Metallic, Red

Running low on expansion slots? Merge USB 3.0 (USB 3.2 Gen 1) and GbE into a single PCIe combo card

This PCIe USB 3.2 Gen 1 card couples your peripheral and network connections into a single, scalable solution.

By combining three USB 3.2 Gen 1 ports and one RJ45 port onto a single card, you only need a single PCIe slot for installation, which lets you free up space for other add-ons or upgrades and get more out of your desktop or server.

Combo-card convenience and cost-savings

If you have separate cards for your USB and network connections, this versatile card overcomes the aggravation of running out of PCIe slots while helping to reduce clutter inside your PC.

This dual-purpose card is perfect for building or upgrading your computer. It helps you save money by avoiding the additional costs of purchasing separate USB 3.2 Gen 1 and Gigabit Ethernet adapters.

Flexible install options and legacy device support

You can rest assured this card will fit in your small form-factor system, if needed. It features a dual-profile design that makes it easy to install in either standard or low-profile cases.

The combo card makes it easy to connect peripherals such as your external hard drives or mobile devices. Plus, it's backward compatible with USB 2.0 and 1.x, so you won't have to replace all of your existing USB devices.

Gigabit connectivity and network management

Functioning as a network adapter, the card delivers wired network access in locations where Wi-Fi® is unavailable or unreliable.

Support for advanced features such as jumbo frames and VLAN tagging means you can optimize network traffic as needed.

Effective USB 3.2 Gen 1 performance enhanced by UASP

This high-performance SuperSpeed USB 3.2 Gen 1 adapter card supports data transfer rates up to 5 Gbps and is enhanced with UASP support, which can perform ~70% faster read speed and 40% faster write speed over traditional USB 3.2 Gen 1, when paired with a UASP-enabled enclosure.

The PEXUSB3S3GE is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Ports & interfaces

Connectivity technology: Wired
Host interface: PCI Express
Interface: Ethernet
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity: 3
USB version: 3.2 Gen 1 (3.1 Gen 1)
PCI version: 2.0
PCI Card form factor: Full-height (low-profile)

Network

Maximum data transfer rate: 5000 Mbit/s
Networking standards: IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Feature: Ethernet LAN
Ethernet LAN data rates: 10,100,1000 Mbit/s
Cabling technology: 10/100/1000BaseT(X)
Feature: Wake-on-LAN ready
Feature: Auto MDIX IEEE
Feature: Full duplex
Feature: Jumbo frames support
Feature: Auto-negotiation
Jumbo frames: 9000
Feature: VLAN tagging

Design

Product colour: Metallic, Red
Feature: Internal
Chipset: Renesas / NEC - µPD720201, Realtek - RTL8153
LED indicators: Activity, Link
Mean time between failures (MTBF): 1920042 h
Certification: CE, FCC

System requirements

Linux operating systems supported: Yes
Server operating systems supported: Windows Server 2008 R2, Windows Server 2012

Operational conditions

Operating temperature (T-T): 5 - 50 °C
Storage temperature (T-T): -25 - 70 °C
Operating relative humidity (H-H): 20 - 80%

Weight & dimensions

Width: 18 mm
Depth: 77 mm
Height: 120 mm
Weight: 60 g

Packaging data

Feature: Drivers included
Quantity per pack: 1 pc(s)
Package width: 143 mm
Package depth: 174 mm
Package height: 33 mm
Package weight: 150 g

Packaging content

Feature: Mounting brackets included
Feature: Manual

Technical details

Compliance certificates: RoHS

Logistics data

Harmonized System (HS) code: 85176990
Master (outer) case width: 378 mm
Master (outer) case length: 496 mm
Master (outer) case height: 320 mm
Products per master (outer) case: 60 pc(s)

Other features

Feature: Flow control support
USB data transfer rates: 5000 Mbit/s
Feature: UASP support
