StarTech.com MCM1110SFP network media converter

StarTech.com Multi-Mode (MM) / Single Mode (SM) Fiber Media Converter for 10/100/1000 Networks, Standalone Gigabit Ethernet to Fiber Converter, Open SFP Slot - TAA. Maximum data transfer rate: 1000 Mbit/s, Converter input interface: 1000Base-T, 100Base-TX, 10Base-T, Converter output interface: 1000Base-LX, 1000Base-SX. Fiber mode structure: Multi-mode, Single-mode, Mean time between failures (MTBF): 50000 h. LED indicators: Activity, Link, Power, Product colour: Black, Housing material: Steel. Fiber optic connector: SFP, Connectivity technology: Wired. Input voltage: 100 - 240 V, Input current: 1 A, Output voltage: 5 V
Convert and extend different networks over a Gigabit fiber cable connection using the SFP of your choice
This fiber media converter offers an easy, cost-effective way to extend your network over fiber, using the SFP of your choice. It converts a copper RJ45 Ethernet connection to Gigabit fiber to extend your network over longer distances or connect workstations to switches. The converter provides a powerful networking solution for campuses, businesses, government facilities, stadiums, or other areas requiring network access.
A cost-effective extension and flexible performance
The Gigabit fiber media converter provides a cost-efficient way to connect your Ethernet network to remote devices over a fiber backbone. It features an open SFP slot that lets you choose the MSA-compliant Gigabit SFP that best suits your fiber connection mode (single / multimode) and distance requirements.
A versatile way to connect different networks
Fully compatible with 10/100/1000Base-T Ethernet networks, the fiber media converter supports auto negotiation to bridge different speed networks and devices to a Gigabit fiber network. It provides versatile connectivity to your existing networks and devices, allowing you to maximize the usage and performance of legacy equipment.
Installation is fast and easy
The unmanaged fiber media converter has a standalone design with simple plug-and-play set-up to ensure fast and easy installation. Compact in size, the converter gives you flexible installation options - including a wall mounting option.

Network

Maximum data transfer rate: 1000 Mbit/s
Converter input interface: 1000Base-T, 100Base-TX, 10Base-T
Converter output interface: 1000Base-LX, 1000Base-SX
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3z
Ethernet interface type: Gigabit Ethernet
Ethernet LAN data rates: 10,100,1000 Mbit/s
Jumbo frames support: Yes
Auto MDI/MDI-X: Yes
Duplex system: Full

Performance

Wavelength-division multiplexing (WDM): Yes
Fiber mode structure: Multi-mode, Single-mode
Mean time between failures (MTBF): 50000 h

Features

Internal: No
LED indicators: Activity, Link, Power
Product colour: Black
Housing material: Steel

Ports interfaces

Connectivity technology: Wired
Ethernet LAN (RJ-45) ports: 1
Fiber ports quantity: 1
Fiber optic connector: SFP
DC-in jack: Yes

Power

Input voltage: 100 - 240 V
Input current: 1 A
Output voltage: 5 V
Output current: 2 A
Power consumption (typical): 5 W
Power over Ethernet (PoE): No
External power adapter: Yes
Power plug type: Type N

Weight dimensions

Width: 70 mm
Depth: 95 mm
Height: 26 mm
Weight: 185 g

Operational conditions

Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -10 - 70 °C
Operating relative humidity (H-H): 5 - 95%

Packaging content

Manual: Yes

Packaging data

Package width: 285 mm
Package depth: 139 mm
Package height: 69 mm
Package weight: 544 g

Certificates

Compliance certificates: RoHS
Certification: CE, FCC

Logistics data

Harmonized System (HS) code: 85176990
Master (outer) case width: 590 mm
Master (outer) case length: 370 mm
Master (outer) case height: 311 mm
Products per master (outer) case: 20 pc(s)
