Extralink EX.6211 network transceiver module
Product reference: 29-5902560366211

Extralink SFP+ WDM Module SFP+ 10G 10Gbps 1270/1330nm, single mode, 20km, LC, DOM, pair, Fiber optic, 10000 Mbit/s, SFP+, LC, 20000 m, 1270 nm

Extralink EX.6211 network transceiver module

Product reference: 29-5902560366211

Extralink SFP+ WDM Module SFP+ 10G 10Gbps 1270/1330nm, single mode, 20km, LC, DOM, pair, Fiber optic, 10000 Mbit/s, SFP+, LC, 20000 m, 1270 nm

You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
69,99 €
73,68 €
Product in warehouse

Guarantee
24 month

Delivery from Europe in
5 - 10
business days

Your message has been successfully sent!
Fill in the required fields*

Extralink SFP+ WDM Module SFP+ 10G 10Gbps 1270/1330nm, single mode, 20km, LC, DOM, pair. SFP transceiver type: Fiber optic, Maximum data transfer rate: 10000 Mbit/s, Interface type: SFP+. Brand compatibility: Cisco. Compliance certificates: CE, RoHS, Certification: FCC. Width: 50 mm, Depth: 20 mm, Height: 75 mm. Quantity per pack: 2 pc(s)

SFP+ 10G WDM 1270/1330NM SM 20KM - a set of economical modules
A set of two SFP single-mode inserts operates bidirectionally on one fiber on waves 1270/1330 nm, over a distance of up to 20 km. The electrical interface of the SFP 10G fiber optic module complies with the SFI electrical specifications. The receiver converts serial optical data at 10 Gbit/s into PECL/CML serial electrical data. The single-mode SFP insert is equipped with a two-wire serial I2C interface for serial identification, digital diagnostics and module control. The improved digital diagnostics monitoring interface allows real time access to the SFP optical module, allowing monitoring of received optical power, laser beam current, laser output power, etc. Single-mode SFP+ modules are dedicated to work with 10 Gbps Ethernet, routers and SONET/SDH switches, 10G/8.5G/4.25G/2.125G/1.0625G optical channels and other 10 Gbps optical links.

Performance

SFP transceiver type: Fiber optic
Maximum data transfer rate: 10000 Mbit/s
Interface type: SFP+
Feature: Single-mode fiber (SMF) supported
Fiber optic connector: LC
Maximum transfer distance: 20000 m
Tx wavelength (min): 1270 nm
Rx wavelength (min): 1330 nm

Features

Brand compatibility: Cisco

Certificates

Compliance certificates: CE, RoHS
Certification: FCC

Weight & dimensions

Width: 50 mm
Depth: 20 mm
Height: 75 mm
Weight: 50 g

Packaging content

Quantity per pack: 2 pc(s)

Packaging data

Package width: 355 mm
Package depth: 440 mm
Package height: 230 mm
Package weight: 12.8 kg

Logistics data

Customs product code (TARIC): 85176200
Country of origin: China


Gamintojo kodas EX.6211
Weight 0 kg
