RUCKUS Networks H550

RUCKUS Networks H550. 2.4 GHz, 5 GHz, Maximum data transfer rate: 1200 Mbit/s. Security algorithms: AES, WPA-TKIP, WPA2, Dynamic PSK, OWE, WPA3-Enterprise, WPA3-Personal, WPA-PSK. Power over Ethernet (PoE). Product colour: White

RUCKUS H550 Indoor Access Point Features
In hotels, apartment buildings, and other multi-dwelling structures, wireless connectivity can carry a hefty price tag. You need to connect a wide range of wired devices - IPTV set-top boxes, IP phones, networked minibars - IoT devices like smart locks and sensors - while delivering a great wireless experience for guests.

The RUCKUS H550 wall-mounted access point, IoT gateway and Ethernet switch makes it easy to support the most demanding in-room connectivity requirements. It starts with RUCKUS patented Wi-Fi optimization intelligence to deliver the industry's highest-performing wireless connectivity. Combine that with four-ports of Gigabit Ethernet to connect multiple in-room wired devices, without extra cabling and add supports for Zigbee® and Bluetooth® Low Energy, as well as other protocols via optional USB modules. Put it all in a sleek low-profile design that can be discretely installed over a standard electrical outlet.

Deliver the full range of in-room services while dramatically reducing cabling, installation time, and construction costs.

Features

Feature: 2.4 GHz
Feature: 5 GHz
Maximum data transfer rate: 1200 Mbit/s
Maximum data transfer rate (2.4 GHz): 574 Mbit/s
Maximum data transfer rate (5 GHz): 1200 Mbit/s
Networking standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Number of users: 512 user(s)
Feature: MIMO
MIMO type: Multi User MIMO
Fit AP mode features: Hotspot 2.0
Feature: VLAN support
Feature: Airtime Fairness (ATF)

Security

Security algorithms: AES, WPA-TKIP, WPA2, Dynamic PSK, OWE, WPA3-Enterprise, WPA3-Personal, WPA-PSK
Feature: Access Control List (ACL)

Protocols

IPv4 & IPv6 features: Dual stack IPv4/IPv6

Ports & interfaces

Ethernet LAN (RJ-45) ports: 5
USB 2.0 ports quantity: 1

Power

Feature: Power over Ethernet (PoE)

Design

Placement: Wall
Product colour: White

Antenna

Antenna type: Internal
Antenna gain level (max): 1 dBi

Weight & dimensions

Width: 89.5 mm
Depth: 178.5 mm
Height: 29.3 mm
Weight: 278 g

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 0 - 95%
