NETGEAR MS308E

NETGEAR MS308E. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 16000 entries, Switching capacity: 40 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x. DC input voltage: 12 V. Wall mountable

NETGEAR 8-port 2.5G Multi-Gigabit Ethernet Plus Switch

MULTI-GIGABIT ETHERNET
8 ports provide up to 2.5 Gbps of dedicated, non-blocking bandwidth each

NON-BLOCKING SWITCHING
40Gbps (10/100/1000 Mbps) line rate fabric ensures congestion-free connectivity to your devices

AUTO-NEGOTIATION
Automatic connection at the highest common speed between the switch and an end device

FANLESS DESIGN
Silent operation makes this switch perfect for noise-sensitive environments

VERSITILE MOUNTING OPTIONS
Install your switch on your desktop or mount it to your wall with the hardware provided in the box

ENERGY EFFICIENT
Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected

Management features

Switch type: Unmanaged
Feature: Quality of Service (QoS) support

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)

Network

Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x
Feature: Full duplex
Feature: Half duplex
Feature: Auto MDI/MDI-X
Feature: Head-of-line (HOL) blocking
Ethernet LAN data rates: 100,1000,2500 Mbit/s
Feature: Cable length detection

Data transmission

Switching capacity: 40 Gbit/s
Forwarding rate: 3.72 Mpps
MAC address table: 16000 entries
Latency (1 Gbps): 4.9 µs
Feature: Jumbo frames support
Jumbo frames: 12288
Packet buffer memory: 1 MB

Design

Product colour: Black
Housing material: Metal
LED indicators: Yes
Feature: Wall mountable
Number of fans: 0 fan(s)

Performance

Noise level: 0 dB
Feature: Fanless
Mean time between failures (MTBF): 3309911 h

Power

Power source: DC
Feature: Power supply included
DC input voltage: 12 V
Input current: 1 A
Input voltage: 12 V
Power consumption (max): 8.1 W

Other features

Warranty period: 5 year(s)

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 70 °C
Operating relative humidity (H-H): 0 - 90%
Storage relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 3000 m
Heat dissipation: 8.27 BTU/h

Weight & dimensions

Width: 158 mm
Depth: 101 mm
Height: 27 mm
Weight: 430 g

Certificates

Compliance certificates: CCC, Low Voltage Directive (LVD)
