NETGEAR MS308

NETGEAR MS308. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 16000 entries, Switching capacity: 40 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x. DC input voltage: 12 V. Wall mountable
NETGEAR 8-Port 2.5G Multi-Gigabit Ethernet Unmanaged Switch
The NETGEAR 8-port 2.5G Multi-Gigabit Unmanaged Switch, MS308, offers businesses an affordable solution to upgrade their networks to multi-gig speeds. Featuring eight (8) 2.5G ports encased in durable metal, the MS308 Multi-Gigabit Ethernet Switch is designed for versatility—it can be placed on a desk, mounted on a wall, or under a table using the included kit.
RELIABLE PERFORMANCE
Superior network performance at non-blocking rate delivers true Multi-Gig speed with no compromise
ENERGY EFFICIENT
Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected
PLUG-AND-PLAY
No software to install. No configuration needed. Zero maintenance required
SILENT OPERATION
The fanless design means zero added noise wherever its located, making it ideal for noise-sensitive environments
VERSATILE MOUNTING OPTIONS
Install your switch on your desktop, or mount it to your wall with the hardware provided in the box.

Management features

Switch type: Unmanaged
Feature: Quality of Service (QoS) support

Ports interfaces

Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)

Network

Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x
Feature: Full duplex
Feature: Half duplex
Feature: Auto MDI/MDI-X
Feature: Head-of-line (HOL) blocking
Ethernet LAN data rates: 100,1000,2500 Mbit/s
Feature: Cable length detection

Data transmission

Switching capacity: 40 Gbit/s
Forwarding rate: 3.72 Mpps
MAC address table: 16000 entries
Latency (1 Gbps): 4.9 µs
Feature: Jumbo frames support
Jumbo frames: 12288
Packet buffer memory: 1 MB

Design

Product colour: Black
Housing material: Metal
LED indicators: Yes
Feature: Wall mountable
Number of fans: 0 fan(s)

Performance

Noise level: 0 dB
Feature: Fanless
Mean time between failures (MTBF): 3309911 h

Power

Power source: DC
Feature: Power supply included
DC input voltage: 12 V
Input current: 1 A
Input voltage: 12 V
Power consumption (max): 7.98 W

Other features

Warranty period: 3 year(s)

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 70 °C
Operating relative humidity (H-H): 0 - 90%
Storage relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 3000 m

Weight dimensions

Width: 158 mm
Depth: 101 mm
Height: 27 mm
Weight: 430 g

Certificates

Compliance certificates: CCC, Low Voltage Directive (LVD)
